Dorman 686-258 Wheel Bearing and Hub Assembly - Front Right

Overview of Dorman 686-258 Wheel Bearing and Hub Assembly

The Dorman 686-258 wheel bearing and hub assembly is engineered for Toyota Camry models, providing reliable driveline performance. Designed with precise specifications, this assembly supports smooth wheel rotation and integrates with the vehicle's anti-lock braking system.

• Compatible with Toyota Camry vehicles
• Includes a circular flange with 5 bolt holes
• Equipped with a 26-spline hub for secure fitment
• Flange diameter measures 139 mm with a 45.3 mm flange offset
• Supports Anti Lock Braking System (ABS) with sensor integration

Technical Specifications and Features

This wheel bearing and hub assembly features a 26-spline hub designed to match the Toyota Camry's driveline requirements. The circular flange includes 5 bolt holes with a 12 mm diameter, arranged on a 114.3 mm bolt circle diameter, ensuring proper mounting and alignment. The flange offset of 45.3 mm and flange diameter of 139 mm are engineered to maintain correct wheel positioning. The assembly supports a wheel pilot diameter of 60 mm and a brake pilot diameter of 62 mm, with a hub pilot diameter of 58 mm for precise fitment. It is compatible with the vehicle's ABS sensor system, although the sensor itself is not included.

Application and Problem Resolution

This Dorman 686-258 assembly is designed specifically for Toyota Camry models, making it suitable for addressing common driveline and wheel hub issues such as:

• Excessive wheel bearing noise or roughness
• Wheel hub looseness or play affecting vehicle stability
• ABS sensor signal interruptions due to faulty hub components
• Uneven brake rotor wear caused by improper hub alignment
• Vibration or wobbling during driving at various speeds

Installation Notes and Tips

When installing the Dorman 686-258 wheel bearing and hub assembly on a Toyota Camry, ensure the following:

• Verify the spline count (26) matches the vehicle's axle shaft
• Confirm the flange bolt hole pattern and bolt circle diameter align with the vehicle hub
• Use proper torque specifications for flange bolts (not included)
• Inspect the ABS sensor wiring and connectors during installation, as the sensor is not included
• Check wheel pilot and brake pilot diameters for correct rotor and wheel fitment

Quality Assurance and Warranty

Dorman manufactures this wheel bearing and hub assembly to meet or exceed OEM standards for fit, form, and function. While the ABS sensor is not included, the assembly is designed to integrate seamlessly with the Toyota Camry's existing ABS system. This part is backed by Dorman's limited warranty, providing coverage against defects in materials and workmanship under normal use.
