Dorman 926-384 Headlight Wiring Harness

Reliable Headlight Wiring Harness for Dodge Ram Models

The Dorman 926-384 headlight wiring harness is designed to provide a secure and efficient electrical connection for your Dodge Ram 1500, 1500 Classic, 2500, and 3500 models. This harness ensures proper headlight function by maintaining consistent power delivery and signal transmission.

Key Features of the Dorman 926-384 Headlight Wiring Harness

• Compatible with Dodge Ram 1500, 1500 Classic, 2500, and 3500 trucks
• Includes 4 wires with 18-gauge measurement for optimal current capacity
• Wire colors: black, green, and red for easy identification during installation
• Three black round male connectors with blade-type terminals for secure connections
• Two terminals on one end and three terminals on the other to match factory wiring

Detailed Product Description

The Dorman 926-384 headlight wiring harness features four 18-gauge wires in black, green, and red, designed to handle the electrical load required for headlight operation in Dodge Ram trucks. The harness includes three black round connectors with male blade terminals, ensuring a reliable and corrosion-resistant connection. With two terminals on one end and three on the other, this harness matches the original equipment specifications, facilitating a straightforward replacement process. This wiring harness is engineered to maintain consistent electrical flow, reducing the risk of flickering or headlight failure.

Common Applications and Issues Addressed

• Replacement for damaged or corroded headlight wiring harnesses in Dodge Ram 1500 and 2500 series
• Resolves intermittent headlight operation caused by faulty wiring connections
• Eliminates electrical shorts or open circuits in the headlight system
• Restores proper headlight function after collision repairs or wiring modifications
• Prevents headlight flickering due to poor terminal contact or wire degradation

Installation Notes and Tips

• Verify compatibility with your specific Dodge Ram model and year before installation
• Disconnect the vehicle battery prior to replacing the wiring harness to avoid electrical hazards
• Use the wire color coding (black, green, red) to match factory wiring for accurate connections
• Ensure all blade terminals are fully seated in the connectors to prevent loose contacts
• Inspect connectors for corrosion or damage and replace if necessary during installation

Quality Assurance and Warranty Information

Dorman manufactures the 926-384 headlight wiring harness to meet or exceed OEM standards for fit, form, and function. Each harness undergoes quality checks to ensure durability and reliable electrical performance. While specific warranty details may vary, Dorman typically offers a limited warranty covering defects in material and workmanship. Refer to Dorman’s official warranty policy for complete information.
