Dorman 930-624 Wheel Bearing and Hub Assembly - Front
| Brand | Dorman 930-624 |
|---|---|
| Position | Front |
| Anti Lock Braking System | Yes |
| Anti Lock Braking System Type | Sensor |
| Bolt Circle Diameter | 4.33 in |
| Brake Pilot Diameter | 3.33 |
| Connector Gender | Male |
| Connector Quantity | 1 |
| Connector Terminal Quantity | 2 |
| Flange Bolt Hole Diameter | 0.4 |
| Flange Bolt Hole Quantity | 3 |
| Flange Bolts Included | No |
| Flange Diameter | 4.33 |
| Flange Offset | 1.54 |
| Flange Shape | Triangular |
| Hub Pilot Diameter | 2.76 |
| Package Contents | Hub Bearing Assembly |
| Spline Quantity | 33 |
| Terminal Gender | Male |
| Wheel Pilot Diameter | 2.55 |
| Wheel Stud Quantity | 5 |
| Wheel Stud Size | 12 |
| Wheel Studs Included | Yes |
| Fits | Chevrolet, Pontiac, and Saturn · 23 vehicles |
Complete repair. Includes the hub and critical bearing components needed for a full replacement.
ABS sensor type. Built with an anti-lock braking system sensor connection.
Studs included. Comes with wheel studs already installed for added convenience.
Cross-references MOOG Hub Assemblies 513206, 12413197 and WE60800 for the same application. See all 3.
Dorman 930-624 Front Wheel Bearing Hub
Dorman 930-624 is a front wheel bearing and hub assembly for specific Chevrolet, Pontiac, and Saturn applications. It combines the hub and critical bearing replacement components in one repair assembly for vehicles with ABS sensor integration.
Key Features
- Front wheel bearing and hub assembly for direct replacement service
- ABS sensor type with 1 male connector and 2 male terminals
- 5 wheel studs included with 12 mm wheel stud size
- 33 spline quantity for the specified driveline application
- Triangular flange shape with 3 flange bolt holes
- Hub pilot diameter: 2.76 in; wheel pilot diameter: 2.55 in
- Brake pilot diameter: 3.33 in; bolt circle diameter: 4.33 in
Detailed Description
This Dorman wheel bearing and hub assembly is built for front-end service on 2004-2007 Saturn Ion, 2005-2010 Chevrolet Cobalt, 2006-2011 Chevrolet HHR, 2006 Pontiac Pursuit, and 2007-2010 Pontiac G5 models with 5-bolt wheels where listed. The assembly includes the hub and bearing replacement components needed for a complete repair on the specified vehicle applications, and it is configured for ABS sensor use. Part number 930-624 is also referenced by OE-style interchange numbers for the same application.
What It Helps Fix
- Wheel bearing noise from worn front hub components
- Front wheel play or looseness at the hub
- ABS warning light concerns related to hub sensor function
- Uneven wheel rotation caused by bearing wear
- Hub-related vibration or roughness during driving
Installation Notes and Tips
Verify front position, wheel bolt pattern, and ABS connector style before installation. Confirm the vehicle application against the listed fitment for 2004-2007 Saturn Ion, 2005-2010 Chevrolet Cobalt, 2006-2011 Chevrolet HHR, 2006 Pontiac Pursuit, and 2007-2010 Pontiac G5. Inspect the mating surfaces, axle splines, and brake components during service, and follow the vehicle manufacturer’s torque specifications for hub and wheel fasteners.
Quality Assurance
Dorman supplies replacement driveline and hub components for specific vehicle applications, and this assembly is built around the listed hub, bearing, and ABS-related specifications for accurate service replacement.
| Year | Make | Model | Submodel | Position | Notes |
|---|---|---|---|---|---|
| 2011 | Chevrolet | HHR | — | Front | — |
| 2010 | Chevrolet | Cobalt | LT Team Canada | Front | 5 Bolt Wheels |
| 2010 | Chevrolet | Cobalt | LT | Front | 5 Bolt Wheels |
| 2010 | Chevrolet | HHR | — | Front | — |
| 2010 | Pontiac | G5 | — | Front | 5 Bolt Wheels |
| 2009 | Chevrolet | Cobalt | LT | Front | 5 Bolt Wheels |
| 2009 | Chevrolet | HHR | — | Front | — |
| 2009 | Pontiac | G5 | — | Front | 5 Bolt Wheels |
| 2008 | Chevrolet | Cobalt | Sport | Front | 5 Bolt Wheels |
| 2008 | Chevrolet | Cobalt | LT | Front | 5 Bolt Wheels |
| 2008 | Chevrolet | HHR | — | Front | — |
| 2008 | Pontiac | G5 | — | Front | 5 Bolt Wheels |
| 2007 | Chevrolet | Cobalt | — | Front | 5 Bolt Wheels |
| 2007 | Chevrolet | HHR | — | Front | — |
| 2007 | Pontiac | G5 | — | Front | 5 Bolt Wheels |
| 2007 | Saturn | Ion | — | Front | 5 Bolt Wheels |
| 2006 | Chevrolet | Cobalt | — | Front | 5 Bolt Wheels |
| 2006 | Chevrolet | HHR | — | Front | — |
| 2006 | Pontiac | Pursuit | — | Front | 5 Bolt Wheels |
| 2006 | Saturn | Ion | — | Front | 5 Bolt Wheels |
| 2005 | Chevrolet | Cobalt | — | Front | 5 Bolt Wheels |
| 2005 | Saturn | Ion | — | Front | 5 Bolt Wheels |
| 2004 | Saturn | Ion | — | Front | 5 Bolt Wheels |
