Dorman 977-602 Fuel Injection Throttle Body

Electronic Throttle Body for Ford F-150

This Dorman electronic throttle body is a direct replacement for select 2005-2008 Ford F-150 applications. It addresses common throttle body wear concerns with a non-contact Hall effect sensor and shaft seal to help reduce future moisture- and oil-related failures.

Key Features

• Electronic throttle body for gas-powered applications
• Fits 2005-2008 Ford F-150
• Non-contact Hall effect sensor helps reduce internal wear
• Shaft seal helps limit moisture and oil intrusion
• Aluminum housing with black and gray finish
• Throttle position sensor included
• Flanged inlet and non-flanged outlet design
• Part number 977-602 for easy identification

Product Details

Dorman 977-602 is an OE FIX electronic throttle body built for select Ford F-150 trucks from 2005 through 2008. It uses a Hall effect sensor instead of a contact-style internal sensor, which helps reduce wear in the throttle control electronics. The sealed shaft design adds protection against contamination that can contribute to throttle body failure over time. This unit is configured with a 2.87-inch inlet diameter, 2.36-inch outlet diameter, and a 6-terminal blade-style electrical connection.

This part cross-references Cardone New 6E-6011 for the same application. If you are replacing a worn Ford F-150 throttle body, 977-602 provides a direct-fit electronic replacement for the listed model years.

Common Problems This Part Can Address

• Throttle response issues caused by worn internal electronics
• Rough or unstable idle related to throttle body wear
• Driveability problems from moisture intrusion in the throttle assembly
• Oil contamination affecting throttle position control
• Check engine light concerns tied to throttle body performance

Installation Notes and Tips

Verify connector style, inlet and outlet dimensions, and throttle body mounting before installation. Because this unit is electronic, the throttle system may require relearn or calibration procedures after replacement. Inspect the intake tract and related sensors for contamination or damage before installing the new throttle body on your Ford F-150.

Quality Assurance

Dorman engineers this OE FIX throttle body to address common failure points found in original equipment units by using a non-contact sensor and improved sealing strategy. Part number 977-602 is built for direct replacement use on the listed Ford F-150 applications.
