DuraGo BR901714 Disc Brake Rotor - Rear

Overview of DuraGo BR901714 Disc Brake Rotor

The DuraGo BR901714 is a cast iron vented disc brake rotor designed for reliable braking performance. Engineered for select Volvo models, this rotor offers consistent stopping power and durability under various driving conditions.

• Material: Full cast iron construction for strength and heat dissipation
• Vented rotor design to improve cooling and reduce brake fade
• Nominal thickness of 0.79 inches (20 mm) with discard thickness at 0.69 inches (17.5 mm)
• Outside diameter of 12.6 inches (320 mm) suitable for specific Volvo vehicles
• Five mounting bolt holes with a 4.25 inch (108 mm) bolt circle diameter
• Non-directional brake surface for versatile installation
• Conventional rotor type without ABS tone ring

Detailed Product Description

The DuraGo BR901714 disc brake rotor is constructed from full cast iron, providing a balance of durability and effective heat management. Its vented design allows air to circulate between the rotor surfaces, helping to dissipate heat generated during braking and reducing the risk of brake fade. With a nominal thickness of 0.79 inches and a discard thickness of 0.69 inches, this rotor maintains structural integrity throughout its service life. The 12.6-inch outside diameter and five mounting bolt holes with a 4.25-inch bolt circle diameter ensure proper fitment on compatible Volvo models including the S60, S90, V60, V60 Cross Country, V90, V90 Cross Country, XC60, and XC90. The rotor features a non-directional braking surface, allowing for flexible installation without concern for rotor orientation.

Compatible Vehicles and Applications

• Volvo S60
• Volvo S90
• Volvo V60 and V60 Cross Country
• Volvo V90 and V90 Cross Country
• Volvo XC60
• Volvo XC90

This rotor is intended for use in front or rear disc brake systems on these Volvo models, providing consistent braking performance under normal driving conditions.

Common Issues Addressed by DuraGo BR901714

• Brake rotor warping causing vibration during braking
• Reduced braking efficiency due to worn or thin rotors
• Overheating and brake fade from insufficient heat dissipation
• Uneven brake pad wear linked to rotor surface irregularities
• Noise and pulsation caused by damaged or compromised rotors

Installation Notes and Tips

When installing the DuraGo BR901714 rotor, ensure the mounting surface is clean and free of rust or debris. Verify the rotor thickness is above the discard limit of 0.69 inches before installation. Use proper torque specifications for the five mounting bolts to avoid rotor distortion. Since this rotor does not include an ABS tone ring, confirm compatibility with your vehicle’s ABS system. It is recommended to replace brake pads simultaneously to ensure optimal braking performance.

Quality Assurance and Warranty

DuraGo manufactures the BR901714 rotor to meet or exceed OEM specifications for fit, form, and function. The full cast iron construction and vented design contribute to reliable performance and longevity. While specific warranty details are not provided, DuraGo products typically come with a limited warranty against defects in materials and workmanship. Always consult product documentation or the manufacturer for exact warranty terms.
