Dynamic Friction 830-67081L Disc Brake Rotor - Front Left
| Brand | Dynamic Friction 830-67081L |
|---|---|
| Position | Front Left |
| Discard Thickness | 20 |
| Nominal Thickness | 22 |
| Disc Finish | Plain |
| Hat Finish | Geospec silver grey |
| Rust Resistant Coating | Yes |
| Bolt Hole Quantity | 6 |
| Overall Height | 37 |
| Outside Diameter | 250 |
| Height | 37 |
| Surface Type | Slotted x drilled |
| Solid Or Vented Type Rotor | Vented |
| Center Hole Diameter | 81 |
| Stud/Lug Hole Quantity | 6 |
| Stud/Lug Hole Diameter | 10.6 |
| Directional or Non-Directional Brake Surface | Directional |
| Bolt Circle Diameter | 103 |
| Stud/Lug Hole Circle Diameter | 103 |
| Product line | DFC Geoperformance Rotor - Drilled and Slotted |
| Fits | Nissan · 13 vehicles |
OE-style fit. Built for direct replacement in the listed brake applications.
Drilled and slotted. Surface design promotes consistent pad contact and braking response.
Rust-resistant coating. Helps protect exposed rotor surfaces from corrosion.
Overview
This Dynamic Friction Geoperformance disc brake rotor is built for specific Nissan front-left applications and uses a slotted, drilled surface for consistent brake contact. The 830-67081L part number identifies the correct rotor for the listed fitments, including Nissan Pickup and Nissan D21 models.
Key Features
- Vented rotor design for improved heat management during braking.
- Slotted and drilled braking surface for more consistent pad contact.
- Rust-resistant coating helps protect exposed surfaces.
- Geospec silver gray hat finish for a clean, corrosion-conscious appearance.
- Directional brake surface engineered for the specified installation side.
Detailed Description
The Dynamic Friction 830-67081L is a vented disc brake rotor with a 250 mm outside diameter, 22 mm nominal thickness, and 20 mm discard thickness. It features six bolt holes, a 103 mm bolt circle, and an 81 mm center hole diameter, matching the listed Nissan applications. The DFC Geoperformance Rotor - Drilled and Slotted line combines a plain disc finish with a directional slotted X drilled surface to support stable braking performance under repeated use. This rotor fits 1995-1997 Nissan Pickup, front left, 1990-1994 Nissan D21, front left, 1986-1988 Nissan D21, front left, 1989 Nissan D21, front left, and 1985 Nissan 720, front left. The 830-67081L part number should be verified against the vehicle’s existing rotor dimensions and fitment notes before ordering.
What It Is Used For
- Replacing a worn or scored front-left brake rotor.
- Addressing brake pulsation caused by uneven rotor wear.
- Restoring braking surface contact after heat checking or grooving.
- Replacing a rotor affected by rust on the braking surface or hat area.
Installation Notes and Tips
Confirm the vehicle’s year, model, and fitment notes before installation. This rotor is listed for front-left applications only, with exclusions for heavy-duty D21 models and a specific 1989 D21 production break noted in the fitment data. Measure the existing rotor and compare bolt pattern, center bore, and thickness specifications to ensure proper match. The directional surface must be installed on the correct side.
| Year | Make | Model | Drive Type | Liters | Cylinders | Fuel Type | Position | Notes |
|---|---|---|---|---|---|---|---|---|
| 1997 | Nissan | Pickup | RWD | — | — | — | Front Left | DFC Geoperformance Rotor - Drilled and Slotted |
| 1996 | Nissan | Pickup | RWD | — | — | — | Front Left | DFC Geoperformance Rotor - Drilled and Slotted |
| 1995 | Nissan | Pickup | RWD | 2.4L | L4 | — | Front Left | DFC Geoperformance Rotor - Drilled and Slotted |
| 1994 | Nissan | D21 | RWD | 3.0L | V6 | — | Front Left | Except Heavy Duty; DFC Geoperformance Rotor - Drilled and Slotted |
| 1993 | Nissan | D21 | RWD | 3.0L | V6 | — | Front Left | Except Heavy Duty; DFC Geoperformance Rotor - Drilled and Slotted |
| 1992 | Nissan | D21 | RWD | 3.0L | V6 | — | Front Left | Except Heavy Duty; DFC Geoperformance Rotor - Drilled and Slotted |
| 1991 | Nissan | D21 | RWD | 3.0L | V6 | — | Front Left | Except Heavy Duty; DFC Geoperformance Rotor - Drilled and Slotted |
| 1990 | Nissan | D21 | RWD | 3.0L | V6 | — | Front Left | Except Heavy Duty; DFC Geoperformance Rotor - Drilled and Slotted |
| 1989 | Nissan | D21 | RWD | 3.0L | V6 | — | Front Left | From 8/89; DFC Geoperformance Rotor - Drilled and Slotted |
| 1988 | Nissan | D21 | RWD | 3.0L | V6 | — | Front Left | Except Heavy Duty; DFC Geoperformance Rotor - Drilled and Slotted |
| 1987 | Nissan | D21 | RWD | 3.0L | V6 | — | Front Left | Except Heavy Duty; DFC Geoperformance Rotor - Drilled and Slotted |
| 1986 | Nissan | D21 | RWD | 3.0L | V6 | — | Front Left | Except Heavy Duty; DFC Geoperformance Rotor - Drilled and Slotted |
| 1985 | Nissan | 720 | RWD | — | — | GAS | Front Left | From 11/85; DFC Geoperformance Rotor - Drilled and Slotted |
