Dynamite Friction 631-67018R Disc Brake Rotor - Rear Right

Overview of Dynamite Friction DFC Brake Rotor

The Dynamite Friction DFC Brake Rotor - Drilled and Slotted - Silver (part number 631-67018R) is engineered for Nissan 200SX and 300ZX models. This solid disc brake rotor features a directional, slotted and drilled surface designed to enhance braking performance and heat dissipation.

• Compatible with Nissan 200SX and 300ZX
• Part Number: 631-67018R
• Solid disc rotor with drilled and slotted surface
• Directional brake surface for optimized performance
• Rust resistant zinc silver hat finish
• 5 bolt holes with 114.3 mm bolt circle diameter
• Nominal thickness of 10 mm and discard thickness of 9 mm
• Overall diameter of 290 mm and height of 47 mm

Product Line Details: DFC Brake Rotor - Drilled and Slotted - Silver

The DFC Brake Rotor - Drilled and Slotted - Silver line by Dynamite Friction offers rotors with a combination of drilled holes and slots on the braking surface. This design improves water and gas evacuation during braking, which helps maintain consistent stopping power. The zinc silver hat finish provides corrosion resistance, extending rotor life. This product line is tailored for drivers seeking reliable braking components compatible with specific Nissan models.

Technical Specifications and Features

This disc brake rotor is a solid type with a nominal thickness of 10 mm and a discard thickness of 9 mm, ensuring safe replacement intervals. The rotor's surface is both drilled and slotted, which aids in heat dissipation and reduces brake fade under demanding conditions. The directional surface pattern is designed to optimize braking efficiency by channeling debris and gases away from the pad contact area.

The rotor measures 290 mm in outside diameter and 47 mm in overall height, with a center hole diameter of 68.1 mm. It features 5 bolt holes with a bolt circle diameter of 114.3 mm and stud/lug hole diameter of 12.75 mm, matching the specifications required for Nissan 200SX and 300ZX vehicles. The zinc silver coating on the hat area provides rust resistance, helping maintain structural integrity and appearance over time.

Applications and Problem Solving

• Replacement rotor for worn or warped brake rotors on Nissan 200SX and 300ZX
• Improves heat dissipation to reduce brake fade during aggressive driving
• Helps maintain consistent braking performance in wet conditions due to drilled and slotted design
• Addresses rotor corrosion issues with rust resistant coating
• Restores proper rotor thickness and braking surface for safe stopping

Installation Notes and Tips

Ensure the rotor thickness is above the discard thickness of 9 mm before installation. Clean the rotor surface to remove any protective coatings or debris prior to mounting. Verify bolt hole alignment with the 5-lug pattern and 114.3 mm bolt circle diameter specific to Nissan 200SX and 300ZX. Use proper torque specifications for lug nuts to avoid rotor warping. It is recommended to replace brake pads when installing new rotors for optimal performance.

Quality Assurance

Dynamite Friction manufactures the 631-67018R rotor to meet OEM specifications for fitment and performance on Nissan 200SX and 300ZX models. The rust resistant zinc silver finish helps extend rotor life by preventing corrosion. While no specific warranty information is provided, this rotor is designed to maintain structural integrity and braking efficiency under normal operating conditions.
