Elring 169.780 Engine Valve Cover Gasket
| Brand | Elring 169.780 |
|---|---|
| Material | Zinc-copper brazing alloy (zn-cu) |
| Fits | Scion and Toyota · 48 vehicles |
Valve cover gasket. Seals the engine valve cover to help keep oil contained.
Zinc-copper alloy. Uses a brazing material chosen for durable sealing performance.
Cross-references Beck/Arnley 036-1555, MAHLE VS50374 and Victor Reinz 15-53088-01 for the same application. See all 10.
Elring 169.780 Engine Valve Cover Gasket
Elring 169.780 is an engine valve cover gasket for select Toyota, Scion, and Prius applications. It is built with a zinc-copper brazing alloy (Zn-Cu), a material choice suited to sealing-system service where stable joining and durability matter.
Compatible with Toyota Prius C, Toyota Yaris, Toyota Prius, Scion xA, Scion xB, and Toyota Echo applications, this part is a direct-fit option for a range of 2000-2021 vehicles. The Elring 169.780 part number is also referenced by several aftermarket cross numbers for the same application.
Key Features
- Engine valve cover gasket for sealing-system service
- Zinc-copper brazing alloy (Zn-Cu) material
- Fits select Toyota, Scion, and Prius applications
- Elring 169.780 for catalog and service matching
- Cross-references Beck/Arnley 036-1555 and MAHLE VS50374
Detailed Description
This Elring valve cover gasket is intended for vehicles that require a sealing-system component matched to the engine valve cover area. The zinc-copper brazing alloy construction supports consistent material performance in applications where sealing integrity is important. For buyers searching for a Toyota Prius valve cover gasket, Toyota Yaris valve cover gasket, or Scion xB engine gasket, Elring 169.780 provides a cataloged replacement option with broad vehicle coverage.
Fitment includes 2012-2021 Toyota Prius C, 2004-2020 Toyota Yaris, 2001-2009 Toyota Prius, 2004-2006 Scion xA, 2004-2006 Scion xB, and 2000-2005 Toyota Echo. This part cross-references Beck/Arnley 036-1555 and MAHLE VS50374 for the same application.
What It Helps Address
- Oil seepage at the valve cover sealing surface
- Loss of sealing integrity around the engine cover area
- Maintenance replacement for aging gasket material
- Service needs on Toyota Prius, Toyota Yaris, and Scion xB engines
- Catalog matching for Elring 169.780 replacement searches
Installation Notes and Tips
Confirm engine application by year, make, and model before installation. Clean the mating surfaces thoroughly and inspect the valve cover and surrounding components for damage or warpage before fitting the new gasket. Follow the vehicle service procedure and torque specifications for the engine being serviced.
Quality Assurance
Elring is a recognized sealing-systems brand used in engine service applications. Part number 169.780 is cataloged for the listed Toyota and Scion fitments and cross-references multiple aftermarket numbers for application matching.
| Year | Make | Model | Submodel | Body Type | Drive Type | Liters | Cylinders | Fuel Type | Notes |
|---|---|---|---|---|---|---|---|---|---|
| 2021 | Toyota | Prius C | — | — | — | 1.5L | L4 | FULL HYBRID EV-GAS (FHEV) | — |
| 2020 | Toyota | Prius C | — | — | — | 1.5L | L4 | FULL HYBRID EV-GAS (FHEV) | — |
| 2020 | Toyota | Yaris | Base | Hatchback | FWD | 1.5L | L4 | — | — |
| 2019 | Toyota | Prius C | — | — | — | 1.5L | L4 | — | — |
| 2019 | Toyota | Yaris | CE | Hatchback | FWD | 1.5L | L4 | — | — |
| 2018 | Toyota | Prius C | — | — | — | 1.5L | L4 | — | — |
| 2018 | Toyota | Yaris | CE | Hatchback | FWD | 1.5L | L4 | — | — |
| 2017 | Toyota | Prius C | — | — | — | 1.5L | L4 | — | — |
| 2017 | Toyota | Yaris | CE | Hatchback | FWD | 1.5L | L4 | — | — |
| 2016 | Toyota | Prius C | — | — | — | 1.5L | L4 | — | — |
| 2016 | Toyota | Yaris | — | — | — | — | — | — | — |
| 2015 | Toyota | Prius C | — | — | — | 1.5L | L4 | — | — |
| 2015 | Toyota | Yaris | — | — | — | — | — | — | — |
| 2014 | Toyota | Prius C | — | — | — | 1.5L | L4 | — | — |
| 2014 | Toyota | Yaris | — | — | — | — | — | — | — |
| 2013 | Toyota | Prius C | — | — | — | 1.5L | L4 | — | — |
| 2013 | Toyota | Yaris | — | — | — | — | — | — | — |
| 2012 | Toyota | Prius C | — | — | — | 1.5L | L4 | — | — |
| 2012 | Toyota | Yaris | — | — | — | — | — | — | — |
| 2011 | Toyota | Yaris | — | — | — | — | — | — | — |
| 2010 | Toyota | Yaris | — | — | — | — | — | — | — |
| 2009 | Toyota | Prius | — | — | — | — | — | — | — |
| 2009 | Toyota | Yaris | — | — | — | — | — | — | — |
| 2008 | Toyota | Prius | — | — | — | — | — | — | — |
| 2008 | Toyota | Yaris | — | — | — | — | — | — | — |
| 2007 | Toyota | Prius | — | — | — | — | — | — | — |
| 2007 | Toyota | Yaris | — | — | — | — | — | — | — |
| 2006 | Scion | xA | — | — | — | — | — | — | — |
| 2006 | Scion | xB | — | — | — | — | — | — | — |
| 2006 | Toyota | Prius | — | — | — | — | — | — | — |
| 2006 | Toyota | Yaris | — | — | — | — | — | — | — |
| 2005 | Scion | xA | — | — | — | — | — | — | — |
| 2005 | Scion | xB | — | — | — | — | — | — | — |
| 2005 | Toyota | Echo | — | — | — | — | — | — | — |
| 2005 | Toyota | Prius | — | — | — | — | — | — | — |
| 2005 | Toyota | Yaris | SOL | Hatchback | FWD | 1.3L | L4 | — | — |
| 2004 | Scion | xA | — | — | — | — | — | — | — |
| 2004 | Scion | xB | — | — | — | — | — | — | — |
| 2004 | Toyota | Echo | — | — | — | — | — | — | — |
| 2004 | Toyota | Prius | — | — | — | — | — | — | — |
| 2004 | Toyota | Yaris | Base | Hatchback | FWD | 1.3L | L4 | — | — |
| 2003 | Toyota | Echo | — | — | — | — | — | — | — |
| 2003 | Toyota | Prius | — | — | — | — | — | — | — |
| 2002 | Toyota | Echo | — | — | — | — | — | — | — |
| 2002 | Toyota | Prius | — | — | — | — | — | — | — |
| 2001 | Toyota | Echo | — | — | — | — | — | — | — |
| 2001 | Toyota | Prius | — | — | — | — | — | — | — |
| 2000 | Toyota | Echo | — | — | — | — | — | — | — |
