Elring 912.270 Engine Valve Cover Gasket
| Brand | Elring 912.270 |
|---|---|
| Material | Acm (polyacrylate) |
| Thickness | 13.0 |
| Inner Diameter [Mm] | 90 |
| Outer Diameter [Mm] | 110 |
| Radial Shaft Seal Design | Aw |
| Fits | INFINITI and Nissan · 33 vehicles |
ACM construction. Polyacrylate material supports consistent sealing in engine service.
Defined gasket profile. 13.0 mm thickness helps match the specified sealing interface.
Application-specific sizing. 90 mm inner diameter and 110 mm outer diameter are listed for the fitment.
Cross-references 13276-EZ30A for the same application. See all 1.
Engine Valve Cover Gasket Overview
Elring 912.270 is an engine valve cover gasket built for specific Nissan and INFINITI applications. It uses ACM (polyacrylate) material and a 13.0 mm thickness to support a precise sealing interface in the valve cover area.
Compatible With Nissan Armada, Nissan TITAN, Nissan TITAN XD, INFINITI QX80, and INFINITI QX56 applications listed below. The Elring 912.270 part number is also referenced for the same application under 13276-EZ30A.
Key Features
- ACM (polyacrylate) construction for sealing performance in engine service.
- 13.0 mm thickness for a defined gasket profile.
- 90 mm inner diameter and 110 mm outer diameter for the specified application.
- Elring sealing component engineered for engine valve cover service.
Detailed Description
This Elring valve cover gasket is specified for fitments including 2021-2024 Nissan Armada, 2017-2024 Nissan TITAN, 2017-2020 Nissan Armada, 2014-2019 INFINITI QX80, 2016 Nissan TITAN XD, and 2012 INFINITI QX56. The 912.270 part number should be matched to the vehicle application and the listed dimensional notes, especially where 90 mm inner diameter and 110 mm outer diameter are called out.
For Nissan Armada and Nissan TITAN engine sealing service, this gasket provides the material and dimensional details needed for a direct replacement selection. Elring 912.270 is also a useful reference when cross-checking the 13276-EZ30A interchange number.
What It Is Used For
- Replacing a worn or flattened valve cover gasket.
- Addressing oil seepage from the valve cover sealing area.
- Restoring a proper seal after engine service.
- Correcting leaks related to gasket hardening or age.
Installation Notes and Tips
Confirm the engine application, gasket dimensions, and any fitment notes before installation. Clean the sealing surfaces thoroughly and inspect the valve cover for damage or distortion before fitting the new gasket. Match the part number 912.270 to the vehicle listing to avoid application errors.
Quality Assurance
Elring is a recognized sealing-system manufacturer, and this gasket is built to the listed material and dimensional specifications for the stated applications.
| Year | Make | Model | Submodel | Body Type | Drive Type | Liters | Cylinders | Fuel Type | Notes |
|---|---|---|---|---|---|---|---|---|---|
| 2024 | Nissan | Armada | Midnight Edition | Sport Utility | RWD | 5.6L | V8 | — | — |
| 2024 | Nissan | TITAN | Platinum Reserve | Crew Cab Pickup | 4WD | 5.6L | V8 | — | — |
| 2023 | Nissan | Armada | Midnight Edition | Sport Utility | RWD | 5.6L | V8 | — | — |
| 2023 | Nissan | TITAN | Platinum Reserve | Crew Cab Pickup | 4WD | 5.6L | V8 | — | — |
| 2022 | Nissan | Armada | Midnight Edition | Sport Utility | RWD | 5.6L | V8 | — | — |
| 2022 | Nissan | TITAN | Platinum Reserve | Crew Cab Pickup | 4WD | 5.6L | V8 | — | — |
| 2021 | Nissan | Armada | Midnight Edition | Sport Utility | RWD | 5.6L | V8 | — | — |
| 2021 | Nissan | TITAN | Platinum | Crew Cab Pickup | 4WD | 5.6L | V8 | — | — |
| 2020 | Nissan | Armada | — | — | RWD | 5.6L | V8 | GAS | Inner Diameter: 90mm; Outer Diameter: 110mm |
| 2020 | Nissan | Armada | — | — | AWD | 5.6L | V8 | GAS | Inner Diameter: 90mm; Outer Diameter: 110mm |
| 2020 | Nissan | TITAN | Platinum | Crew Cab Pickup | 4WD | 5.6L | V8 | — | — |
| 2019 | INFINITI | QX80 | — | — | RWD | 5.6L | V8 | GAS | Inner Diameter: 90mm; Outer Diameter: 110mm |
| 2019 | INFINITI | QX80 | — | — | AWD | 5.6L | V8 | GAS | Inner Diameter: 90mm; Outer Diameter: 110mm |
| 2019 | Nissan | Armada | — | — | RWD | 5.6L | V8 | GAS | Inner Diameter: 90mm; Outer Diameter: 110mm |
| 2019 | Nissan | Armada | — | — | AWD | 5.6L | V8 | GAS | Inner Diameter: 90mm; Outer Diameter: 110mm |
| 2019 | Nissan | TITAN | Platinum Reserve | Crew Cab Pickup | 4WD | 5.6L | V8 | — | — |
| 2018 | INFINITI | QX80 | — | — | RWD | 5.6L | V8 | GAS | Inner Diameter: 90mm; Outer Diameter: 110mm |
| 2018 | INFINITI | QX80 | — | — | AWD | 5.6L | V8 | GAS | Inner Diameter: 90mm; Outer Diameter: 110mm |
| 2018 | Nissan | Armada | — | — | RWD | 5.6L | V8 | GAS | Inner Diameter: 90mm; Outer Diameter: 110mm |
| 2018 | Nissan | Armada | — | — | AWD | 5.6L | V8 | GAS | Inner Diameter: 90mm; Outer Diameter: 110mm |
| 2018 | Nissan | TITAN | Platinum Reserve | Crew Cab Pickup | 4WD | 5.6L | V8 | — | — |
| 2017 | INFINITI | QX80 | — | — | AWD | 5.6L | V8 | GAS | Inner Diameter: 90mm; Outer Diameter: 110mm |
| 2017 | Nissan | Armada | — | — | RWD | 5.6L | V8 | GAS | Inner Diameter: 90mm; Outer Diameter: 110mm |
| 2017 | Nissan | Armada | — | — | AWD | 5.6L | V8 | GAS | Inner Diameter: 90mm; Outer Diameter: 110mm |
| 2017 | Nissan | TITAN | Platinum Reserve | Crew Cab Pickup | 4WD | 5.6L | V8 | — | — |
| 2016 | INFINITI | QX80 | — | — | RWD | 5.6L | V8 | GAS | Inner Diameter: 90mm; Outer Diameter: 110mm |
| 2016 | INFINITI | QX80 | — | — | AWD | 5.6L | V8 | GAS | Inner Diameter: 90mm; Outer Diameter: 110mm |
| 2016 | Nissan | TITAN XD | Platinum Reserve | Crew Cab Pickup | RWD | 5.6L | V8 | — | — |
| 2015 | INFINITI | QX80 | — | — | RWD | 5.6L | V8 | GAS | Inner Diameter: 90mm; Outer Diameter: 110mm |
| 2015 | INFINITI | QX80 | — | — | AWD | 5.6L | V8 | GAS | Inner Diameter: 90mm; Outer Diameter: 110mm |
| 2014 | INFINITI | QX80 | — | — | RWD | 5.6L | V8 | GAS | Inner Diameter: 90mm; Outer Diameter: 110mm |
| 2014 | INFINITI | QX80 | — | — | AWD | 5.6L | V8 | GAS | Inner Diameter: 90mm; Outer Diameter: 110mm |
| 2012 | INFINITI | QX56 | Base | Sport Utility | AWD | 5.6L | V8 | — | — |
