FAG 101641 Wheel Bearing - Front
OE Quality 60-Day Returns
FAG

FAG 101641 Wheel Bearing - Front

Brand FAG 101641
Position Front
Height 1.654
Height 42
Inside Diameter 1.772
Inside Diameter 45
Outside Diameter 3.307
Outside Diameter 84
Fits Honda · 21 vehicles

Compact bearing unit. Defined clearance and lifetime sealing reduce maintenance needs.

Angular contact design. Built for dependable performance in demanding conditions.

Wheel bearing. A rugged, sealed replacement for smooth rotation.

Cross-references National 510074, Schaeffler 101641 and SKF FW38 for the same application. See all 3.

$67.77Free shipping
Out of stock
Step 1 — Confirm fitment
Free return shipping if it doesn't fit when you check fitment here first.

Select your vehicle to confirm fitment
Verify this part fits before purchasing — free returns if it doesn't
Step 2 — Quantity
Order total $67.77
Free shipping to the continental U.S.
Free returns within 60 days if it doesn't fit when fitment is verified.
Not what you need? See all Wheel Bearing options

Front Wheel Bearing for Honda Element and CR-V

FAG 101641 is a first-generation front wheel bearing built as a compact, sealed unit with preset bearing clearance and lifetime lubrication. It is engineered for Honda Element and Honda CR-V front applications where precise wheel support, low maintenance, and stable ABS signal performance matter.

Key Features

  • Inside diameter: 45 mm (1.772 in)
  • Outside diameter: 84 mm (3.307 in)
  • Height: 42 mm (1.654 in)
  • First-generation compact bearing unit with sealed, for-life lubrication
  • Preset bearing clearance for consistent operation
  • Angular contact ball bearing design for front and rear wheel use in demanding service conditions
  • Built-in magnetic strip for ABS sensor orientation
  • Cross-references National 510074 and SKF FW38 for the same application

Detailed Description

This FAG 101641 wheel bearing is designed for front hub service on 2002-2006 Honda CR-V and 2003-2011 Honda Element models. The sealed construction reduces maintenance needs, while the compact bearing design supports reliable wheel rotation and load handling in everyday driving. The integrated magnetic strip must face the ABS sensor during installation to maintain correct signal pickup.

For buyers searching for a Honda Element front wheel bearing 101641 or a Honda CR-V front wheel bearing 101641, this part matches the listed OE-style dimensions and application details. The bearing’s angular contact ball design is suited to front and rear wheel positions across demanding operating conditions, and the preset clearance helps maintain consistent fit and function.

What This Part Helps Address

  • Wheel noise from a worn front bearing
  • Excessive play or looseness at the hub
  • ABS warning concerns related to incorrect magnetic ring orientation
  • Rough wheel rotation caused by bearing wear
  • Loss of smooth, stable front-end wheel support

Installation Notes and Tips

  • Fits 2003-2011 Honda Element, front.
  • Fits 2002-2006 Honda CR-V, front.
  • Install the magnetic strip toward the ABS sensor side.
  • Use a magnet indicator or a magnet-reactive item, such as a paper clip, to confirm the correct side before assembly.
  • A protective metal cover may also indicate the proper installation side.
  • Verify hub and knuckle condition before pressing in the bearing.

Quality Assurance

FAG is part of Schaeffler’s bearing lineup, and this 101641 wheel bearing is built to the dimensional and functional requirements listed for the application. It is a sealed, lubricated bearing unit intended for direct front-wheel service on the specified Honda models.

Related reading

This part fits 21 vehicles
Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
YearMakeModelSubmodelPositionNotes
2011HondaElementLXFrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2011HondaElementEXFrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2010HondaElementLXFrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2010HondaElementEXFrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2009HondaElementLXFrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2009HondaElementEXFrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2008HondaElementLXFrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2008HondaElementEXFrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2007HondaElementEXFrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2007HondaElementLXFrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2006HondaCR-V—FrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2006HondaElement—FrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2005HondaCR-V—FrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2005HondaElement—FrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2004HondaCR-VEXFrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2004HondaElementLXFrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2004HondaElementEXFrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2003HondaCR-VEXFrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2003HondaElementEXFrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2002HondaCR-VLXFrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2002HondaCR-VEXFrontSchaeffler BRG Global Number 101641; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
Directly replaces or cross-references 3 part numbers
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
National — 510074Schaeffler — 101641SKF — FW38
