FAG 102211 Wheel Bearing and Hub Assembly - Front
| Brand | FAG 102211 |
|---|---|
| Position | Front |
| 3 | |
| Number of Bolt Holes | 3 |
| Number of Hub Bolts | 6 |
| Fits | Cadillac · 7 vehicles |
Maintenance-free hub. Compact, lightweight design with proven bearing performance.
Integral mounting flange. Simplifies mounting for brake, disc, and wheel components.
Wheel bearing and hub assembly. Combines bearing and hub functions in one unit.
Cross-references ATP 102211, MOOG Hub Assemblies 513198 and SKF BR930363 for the same application. See all 4.
FAG 102211 Wheel Bearing Hub Assembly
The FAG 102211 wheel bearing and hub assembly is a front hub solution for select Cadillac applications. It combines a compact, lightweight design with a maintenance-free bearing construction and an integral mounting flange for brake, disc, and wheel attachment.
Key Features
- Wheel bearing and hub assembly for front axle applications
- Maintenance-free design for reduced service requirements
- Compact, lightweight construction
- Integral mounting flange for brake, disc, and wheel mounting
- 3-bolt hole configuration with 6 hub bolts
- ABS cable included on listed fitments
Application Details
Compatible With 2010 Cadillac STS, front, heavy duty package; Schaeffler BRG Global Number 102211; ABS cable included. Compatible With 2004-2009 Cadillac SRX, front; Schaeffler BRG Global Number 102211; ABS cable included. This FAG 102211 hub assembly is also cross-referenced to Timken HA590078 for the same application.
Built for direct front-wheel service on the Cadillac SRX and Cadillac STS, this FAG 102211 assembly supports the hub, bearing, and wheel mounting interface in one unit. The integrated flange helps simplify alignment of the brake rotor and wheel mounting surfaces while the sealed, maintenance-free bearing design reduces routine service needs.
Common Replacement Reasons
- Front wheel bearing noise or growling
- Excessive hub play or looseness
- ABS warning light related to hub sensor circuit issues
- Uneven wheel rotation or vibration from hub wear
- Damaged mounting surfaces at the front hub
Installation Notes
Verify front axle fitment by year, model, and notes before installation. Confirm the 3-bolt hole and 6-hub-bolt configuration matches the vehicle application. Inspect related suspension and brake components for wear, and follow factory torque specifications during installation.
Quality Assurance
FAG is known for bearing and hub engineering used in OE-style driveline service parts. The FAG 102211 is built as a maintenance-free hub assembly with an integrated mounting flange for consistent fit and function on the listed Cadillac applications.
| Year | Make | Model | Drive Type | Position | Notes |
|---|---|---|---|---|---|
| 2010 | Cadillac | STS | AWD | Front | w/Heavy Duty Package; Schaeffler BRG Global Number 102211; ABS Cable Included |
| 2009 | Cadillac | SRX | AWD | Front | Schaeffler BRG Global Number 102211; ABS Cable Included |
| 2008 | Cadillac | SRX | AWD | Front | Schaeffler BRG Global Number 102211; ABS Cable Included |
| 2007 | Cadillac | SRX | AWD | Front | Schaeffler BRG Global Number 102211; ABS Cable Included |
| 2006 | Cadillac | SRX | AWD | Front | Schaeffler BRG Global Number 102211; ABS Cable Included |
| 2005 | Cadillac | SRX | AWD | Front | Schaeffler BRG Global Number 102211; ABS Cable Included |
| 2004 | Cadillac | SRX | AWD | Front | Schaeffler BRG Global Number 102211; ABS Cable Included |
