FAG 102559 Wheel Bearing - Front
OE Quality 60-Day Returns
FAG

FAG 102559 Wheel Bearing - Front

Brand FAG 102559
Position Front
Height 1.89
Height 48
Inside Diameter 2.126
Inside Diameter 54
Outside Diameter 3.74
Outside Diameter 95
Fits Honda · 13 vehicles

Compact bearing unit. Preset clearance, lifetime sealing, and for-life lubrication reduce maintenance.

Angular contact design. Built for dependable performance in demanding service conditions.

Wheel bearing. A rugged, sealed unit for smooth, low-maintenance operation.

Cross-references National 510088, Schaeffler 102559 and SKF FW77 for the same application. See all 4.

$63.96Free shipping
In stock · usually ships same day before 1pm CST
Step 1 — Confirm fitment
Free return shipping if it doesn't fit when you check fitment here first.

Select your vehicle to confirm fitment
Verify this part fits before purchasing — free returns if it doesn't
Step 2 — Quantity
Order total $63.96
Free shipping to the continental U.S.
Free returns within 60 days if it doesn't fit when fitment is verified.
Not what you need? See all Wheel Bearing options

Honda Ridgeline Front Wheel Bearing

FAG 102559 is a first-generation front wheel bearing built as a compact, sealed unit with preset bearing clearance and lifetime lubrication. It is engineered for Honda Ridgeline front wheel service where consistent rotation, sealing, and ABS signal accuracy matter.

  • Inside diameter: 54 mm (2.126 in)
  • Outside diameter: 95 mm (3.74 in)
  • Height: 48 mm (1.89 in)
  • Sealed, maintenance-free bearing design
  • Preset bearing clearance for controlled fit and operation
  • Angular contact ball bearing construction for front-wheel use
  • Built-in magnetic strip for ABS sensor orientation

Detailed Product Overview

FAG 102559 is a wheel bearing designed for front axle service on the Honda Ridgeline. Its compact, rugged construction supports demanding road conditions while the sealed design keeps lubrication contained for long-term operation. The integrated magnetic strip must face the ABS sensor during installation, making correct orientation important for proper wheel speed signal performance. This part cross-references National 510088 and SKF FW77 for the same application.

Compatible With 2006-2014 Honda Ridgeline, front and 2017-2020 Honda Ridgeline, front. The FAG 102559 bearing is also a direct search match for Honda Ridgeline front wheel bearing replacement and Honda Ridgeline ABS magnetic wheel bearing service.

Common Problems This Part Can Address

  • Wheel noise from a worn front hub bearing
  • Excessive play or looseness at the front wheel
  • Rough rotation caused by bearing wear or contamination
  • ABS warning concerns related to incorrect magnetic strip orientation
  • Loss of smooth front-end wheel support on a Honda Ridgeline

Installation Notes and Tips

Confirm the magnetic side of the bearing is assembled toward the ABS sensor before installation. A magnet indicator, paper clip, or similar magnet-reactive item can help identify the correct side, and a protective metal cover may also indicate orientation. Verify all dimensions and vehicle application before pressing the bearing into place, and follow the service procedure for the Honda Ridgeline front hub assembly.

Quality Assurance

FAG is known for precision bearing engineering, and this wheel bearing is manufactured as a sealed, lifetime-lubricated unit with preset clearance for consistent service performance. Part number 102559 is listed with OE-style interchange references for the same front-wheel application.

Related reading

This part fits 13 vehicles
Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
YearMakeModelPositionNotes
2020HondaRidgelineFrontSchaeffler BRG Global Number 102559; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2019HondaRidgelineFrontSchaeffler BRG Global Number 102559; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2018HondaRidgelineFrontSchaeffler BRG Global Number 102559; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2017HondaRidgelineFrontSchaeffler BRG Global Number 102559; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2014HondaRidgelineFrontSchaeffler BRG Global Number 102559; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2013HondaRidgelineFrontSchaeffler BRG Global Number 102559; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2012HondaRidgelineFrontSchaeffler BRG Global Number 102559; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2011HondaRidgelineFrontSchaeffler BRG Global Number 102559; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2010HondaRidgelineFrontSchaeffler BRG Global Number 102559; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2009HondaRidgelineFrontSchaeffler BRG Global Number 102559; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2008HondaRidgelineFrontSchaeffler BRG Global Number 102559; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2007HondaRidgelineFrontSchaeffler BRG Global Number 102559; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
2006HondaRidgelineFrontSchaeffler BRG Global Number 102559; This bearing comes with a built in magnetic strip which should be assembled towards the ABS sensor. The correct side can be confirmed by moving an FAG magnet indicator or any magnet reactive product (such as a paper clip) over the end of the bearing. A protective metal cover can also indicate the correct side to be installed.
Directly replaces or cross-references 4 part numbers
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
National — 510088Schaeffler — 102559SKF — FW77Timken — WB000008
