FAG SR3503 Automatic Transmission Repair Sleeve - Front

Overview of FAG SR3503 Automatic Transmission Repair Sleeve

The FAG SR3503 automatic transmission repair sleeve is engineered for precise fitment and reliable performance in select Dodge, Ford, Mitsubishi, and Saab vehicles. Designed to restore proper shaft alignment and sealing, this repair sleeve supports transmission longevity and smooth operation.

• Width on shaft: 0.375 inches (9.525 mm)
• Installation depth: 1.05 inches (26.67 mm)
• Width: 0.516 inches (13.106 mm)
• Shaft diameter: 1.875 inches (47.625 mm)
• Flange diameter: 2.203 inches (55.956 mm)

Detailed Product Description

The FAG SR3503 automatic transmission repair sleeve is manufactured to exacting specifications to ensure compatibility with various transmission shafts. Its dimensions, including a shaft diameter of 1.875 inches and flange diameter of 2.203 inches, provide a secure fit that maintains the integrity of the transmission assembly. The sleeve’s installation depth of 1.05 inches allows for proper seating within the transmission housing, while the width on shaft measurements ensure a tight seal and alignment. This part is suitable for use in Dodge Ram 1500, Ram 2500, Ram 3500 series, Ford Aerostar, B150, B250, B3500, Mitsubishi Eclipse, and Saab 9-3, 9-5, 900, and 9000 models.

Applications and Common Repair Uses

• Restores worn or damaged transmission shaft surfaces
• Prevents fluid leaks by providing a precise sealing surface
• Corrects shaft misalignment issues within the transmission
• Supports smooth gear engagement and shifting performance
• Extends transmission service life by maintaining component integrity

Installation Notes and Tips

Proper installation of the FAG SR3503 repair sleeve requires careful measurement and alignment. Ensure the transmission shaft and housing are clean and free of debris before installation. Use appropriate tools to press the sleeve evenly onto the shaft to avoid damage. Verify the installation depth of 1.05 inches for optimal fit. It is recommended to inspect related transmission components during installation to address any additional wear or damage.

Quality Assurance and Warranty

FAG parts are manufactured to meet stringent quality standards, ensuring durability and reliable performance in automotive transmission applications. The SR3503 repair sleeve undergoes rigorous testing to comply with OEM specifications. Warranty coverage details should be confirmed with the parts provider or manufacturer documentation.
