FAG SR3519 Engine Timing Cover Repair Sleeve Kit

Overview of FAG Engine Timing Cover Repair Sleeve Kit SR3519

The FAG SR3519 Engine Timing Cover Repair Sleeve Kit is designed for precise restoration of engine timing cover shafts on select Chevrolet and GMC models. Engineered to exact specifications, this repair sleeve kit ensures a secure fit and reliable performance for vehicles such as the Chevrolet C10, GMC Sierra, and Chevrolet Tahoe.

• Width on shaft options: 0.75 inch (19.05 mm) and 0.875 inch (22.225 mm)
• Installation depth options: 1.5 inch (38.1 mm)
• Shaft diameter compatibility: 2.328 inch (59.131 mm)
• Flange diameter: 2.75 inch (69.85 mm)
• Compatible with a wide range of Chevrolet and GMC trucks and SUVs

Technical Details and Specifications

The SR3519 repair sleeve kit from FAG is manufactured to meet stringent OEM standards, providing a precise fit for engine timing cover shafts. The kit includes sleeves with widths on shaft measuring 0.75 inch (19.05 mm) and 0.875 inch (22.225 mm), accommodating different shaft sizes. Installation depth is standardized at 1.5 inches (38.1 mm), ensuring proper seating within the timing cover assembly. The shaft diameter compatibility of 2.328 inches (59.131 mm) and flange diameter of 2.75 inches (69.85 mm) make this kit suitable for restoring worn or damaged timing cover shafts on various Chevrolet and GMC models.

Compatible Vehicles and Applications

This FAG Engine Timing Cover Repair Sleeve Kit SR3519 is compatible with numerous Chevrolet and GMC vehicles, including but not limited to:

• Chevrolet Bel Air, Blazer, C10, C20, C30, C1500, C2500, C3500
• GMC Sierra models such as K5 Blazer, K10, K20, K30, K1500, K2500, K3500
• Chevrolet Express 2500, Express 3500, Tahoe, Impala, Monte Carlo, Nova
• GMC Savana 2500, Savana 3500, G20, G30, R10, R20, R30 series

Common Issues Addressed by the Repair Sleeve Kit

• Wear and scoring on engine timing cover shafts
• Oil leaks caused by damaged or worn shaft surfaces
• Excessive shaft play leading to timing cover misalignment
• Corrosion or pitting on shaft surfaces affecting seal integrity
• Restoration of proper shaft diameter for seal replacement

Installation Notes and Tips

• Ensure the timing cover and shaft surfaces are clean and free of debris before installation
• Use appropriate press tools to install the repair sleeve without damaging the shaft or cover
• Verify the installation depth of 1.5 inches (38.1 mm) for correct seating
• Inspect the flange diameter fit to ensure proper alignment with the timing cover
• Consult vehicle-specific service manuals for torque specifications and additional installation procedures

Quality Assurance and Warranty Information

FAG manufactures the SR3519 Engine Timing Cover Repair Sleeve Kit to meet rigorous quality standards, ensuring durability and reliable performance. Each kit undergoes strict dimensional and material inspections to guarantee compatibility with specified Chevrolet and GMC models. While specific warranty details may vary, FAG products typically include coverage against manufacturing defects. Refer to FAG’s official documentation for complete warranty terms.
