FAG SS3043 Manual Transmission Seal - Rear

Manual Transmission Seal for GM Applications

The FAG SS3043 manual transmission seal is built for specific Chevrolet and GMC applications that require a precise sealing fit. It uses nitrile sealing material with a rubber spring design, auxiliary lip, and inner shell to help maintain a tight seal at the transmission opening.

Compatible with select Chevrolet C/K trucks, Blazer, Suburban, and GMC truck and van platforms, this seal is a direct-fit option for rear manual transmission service on listed applications. The FAG SS3043 is sized for the specified bore and outside diameter requirements to match the original sealing interface.

Key Features

• FAG manual transmission seal, part number SS3043
• Nitrile sealing material for transmission sealing applications
• Rubber, spring, auxiliary lip, and inner shell construction
• Bore diameter: 2.997 in. / 76.124 mm
• Seal outside diameter: 3.001 in. / 76.225 mm
• Seal width: 2 in. / 9.525 mm
• Cross-references National 410085 and SKF 19970 for the same application

Detailed Description

FAG SS3043 is a manual transmission seal engineered for vehicles that require a rear transmission seal with the listed dimensions and sealing profile. The nitrile sealing material is selected for durability in transmission environments, while the spring-loaded design and auxiliary lip help maintain contact at the sealing surface. This part is used on a wide range of Chevrolet and GMC trucks, vans, and utility models, including Chevrolet C1500, K2500, K5 Blazer, GMC Jimmy, and GMC C/K series applications.

For buyers searching for a rear manual transmission seal for 1970s through early 1990s Chevrolet and GMC platforms, SS3043 provides a focused replacement option. It is also referenced by National 410085 and SKF 19970, which helps when matching an existing seal number during service work.

What This Seal Helps Address

• Transmission fluid leakage at the rear seal area
• Contamination entry from dirt, dust, and moisture
• Grease loss at the sealing interface
• Wear-related sealing issues on older manual transmission applications
• Replacement needs during transmission service or rebuild work

Installation Notes and Tips

Verify bore diameter, outside diameter, and seal width before installation. Confirm the vehicle application and transmission position against the fitment list, especially on Chevrolet K30, P30, C20, and GMC Jimmy rear manual transmission applications noted with Muncie transmission references. Clean the sealing bore and shaft surface thoroughly before installing the new seal to help achieve proper seating and sealing contact.

Quality Assurance

FAG designs seals to meet vehicle manufacturer specifications and works with suppliers to maintain its quality standards. The seal construction is intended to protect wheel-end and transmission components from contamination while helping preserve lubricant over the service life of the bearing or seal assembly.

• Fits 1988-1991 Chevrolet C1500, N/A
• Fits 1988-1991 Chevrolet C2500, N/A
• Fits 1988-1991 Chevrolet C3500, N/A
• Fits 1988-1991 Chevrolet K2500, N/A
• Fits 1988-1991 Chevrolet K3500, N/A
• Fits 1989-1991 Chevrolet R3500, N/A
• Fits 1989-1991 Chevrolet V3500, N/A
• Fits 1988-1991 GMC C1500, N/A
• Fits 1979-1986 GMC C1500, N/A
• Fits 1988-1991 GMC C2500, N/A
• Fits 1979-1986 GMC C2500, N/A
• Fits 1988-1991 GMC C3500, N/A
• Fits 1979-1986 GMC C3500, N/A
• Fits 1975-1991 GMC Jimmy, N/A
• Fits 1988-1991 GMC K1500, N/A
• Fits 1979-1986 GMC K1500, N/A
• Fits 1988-1991 GMC K2500, N/A
• Fits 1979-1986 GMC K2500, N/A
• Fits 1988-1991 GMC K3500, N/A
• Fits 1979-1986 GMC K3500, N/A
• Fits 1987-1991 GMC R3500, N/A
• Fits 1987-1991 GMC V3500, N/A
• Fits 1989 Chevrolet R2500, N/A
• Fits 1985-1989 GMC G1500, N/A
• Fits 1979-1982 GMC G1500, N/A
• Fits 1985-1989 GMC G2500, N/A
• Fits 1979-1982 GMC G2500, N/A
• Fits 1979-1989 GMC P2500, N/A
• Fits 1987-1989 GMC R2500, N/A
• Fits 1988 Chevrolet Blazer, N/A
• Fits 1985-1988 Chevrolet G10, N/A
• Fits 1978-1981 Chevrolet G10, N/A
• Fits 1988 Chevrolet K1500, N/A
• Fits 1987-1988 Chevrolet R20, N/A
• Fits 1987-1988 Chevrolet R30, N/A
• Fits 1987-1988 Chevrolet V30, N/A
• Fits 1987-1988 GMC R2500 Suburban, N/A
• Fits 1987-1988 GMC V1500 Suburban, N/A
• Fits 1987-1988 GMC V2500 Suburban, N/A
• Fits 1987 Chevrolet R10, N/A
• Fits 1987 Chevrolet V20, N/A
• Fits 1987 GMC R1500, N/A
• Fits 1987 GMC V1500, N/A
• Fits 1987 GMC V2500, N/A
• Fits 1980-1986 Chevrolet C10, N/A
• Fits 1983-1986 Chevrolet C20, N/A
• Fits 1979-1981 Chevrolet C20, N/A
• Fits 1979-1986 Chevrolet K20, N/A
• Fits 1982-1986 Chevrolet K30, N/A
• Fits 1980-1986 Chevrolet K5 Blazer, N/A
• Fits 1982-1984 Chevrolet C10 Suburban, N/A
• Fits 1982-1984 Chevrolet K10, N/A
• Fits 1983-1984 Chevrolet K10 Suburban, N/A
• Fits 1968-1974 Chevrolet K10 Suburban, N/A
• Fits 1983-1984 GMC C1500 Suburban, N/A
• Fits 1979-1981 GMC C1500 Suburban, N/A
• Fits 1979-1984 GMC C2500 Suburban, N/A
• Fits 1979-1984 GMC K1500 Suburban, N/A
• Fits 1979-1984 GMC K2500 Suburban, N/A
• Fits 1979-1982 GMC G3500, N/A
• Fits 1980-1981 Chevrolet C20 Suburban, N/A
• Fits 1978-1981 Chevrolet C30, N/A
• Fits 1975-1981 Chevrolet G30, N/A
• Fits 1977-1981 Chevrolet K30, Rear, Muncie Transmission; Schaeffler Seal Global Number 413 3043 100; .375" Width
• Fits 1975-1981 Chevrolet P30, Rear, Muncie Transmission; Schaeffler Seal Global Number 413 3043 100; .375" Width
• Fits 1979-1981 GMC P3500, N/A
• Fits 1979-1980 GMC P1500, N/A
• Fits 1975-1978 Chevrolet C20, Rear, Muncie Transmission; Schaeffler Seal Global Number 413 3043 100; .375" Width
• Fits 1975-1978 Chevrolet C20 Suburban, Rear, Muncie Transmission; Schaeffler Seal Global Number 413 3043 100; .375" Width
• Fits 1975-1978 Chevrolet K20, Rear, Muncie Transmission; Schaeffler Seal Global Number 413 3043 100; .375" Width
• Fits 1968-1978 Chevrolet K20 Suburban, Rear, Muncie Transmission; Schaeffler Seal Global Number 413 3043 100; .375" Width
• Fits 1975-1978 Chevrolet P20, Rear, Muncie Transmission; Schaeffler Seal Global Number 413 3043 100; .375" Width
• Fits 1975-1978 GMC G15, N/A
• Fits 1975-1978 GMC G25, N/A
• Fits 1975-1978 GMC G35, N/A
• Fits 1975-1977 Chevrolet C30, Rear, Manual Transmission Seal Global Number 413 3043 100 with .375" Width
• Fits 1969-1974 Chevrolet Blazer, Rear, RWD; Schaeffler Seal Global Number 413 3043 100; .375" Width
• Fits 1968-1974 Chevrolet C10 Suburban, Rear, RWD; Schaeffler Seal Global Number 413 3043 100; .375" Width
• Fits 1968-1974 Chevrolet C20 Suburban, Rear, Manual Transmission Seal Global Number 413 3043 100 with .375" Width
• Fits 1968-1974 GMC G25/G2500 Van, N/A
• Fits 1971-1974 GMC G35/G3500 Van, N/A
• Fits 1970-1974 GMC Jimmy, Rear, RWD; Schaeffler Seal Global Number 413 3043 100; .375" Width
