FAG SS3652 Manual Transmission Seal - Front

Manual Transmission Seal for OE-Style Service

FAG SS3652 is a manual transmission seal built with a rubber seal body, spring, and auxiliary lip to help maintain a tight sealing surface in demanding drivetrain applications. It uses Viton sealing material and precise dimensions for service on a wide range of import and domestic vehicles, including Suzuki Sidekick, Geo Tracker, and Toyota Corolla applications.

With a 1.496 in bore diameter, 1.502 in outside diameter, and 0.984 in seal width, this seal is sized for accurate replacement work where proper fit and material selection matter. FAG SS3652 is engineered for applications that require dependable sealing against contamination and lubricant loss.

Key Features

• Manual transmission seal for drivetrain sealing service
• Rubber seal design with spring and auxiliary lip
• Viton sealing material for demanding operating conditions
• 1.496 in bore diameter for application-specific fitment
• 1.502 in outside diameter and 0.984 in width
• Cross-references Anchor 9701 for the same application
• Also cross-references part number 4133652100

Detailed Description

FAG SS3652 is designed for vehicles that need a precise manual transmission seal to help keep dirt, dust, and moisture out of the sealed area while retaining lubricant at the transmission interface. The seal construction combines rubber, a spring, and an auxiliary lip to support consistent contact at the sealing surface, while the Viton material adds durability for service environments where heat and fluid exposure are concerns. This part number is commonly searched for Suzuki Samurai, Suzuki Sidekick, Geo Tracker, and Toyota Corolla manual transmission seal replacement needs.

Fits 1989-1998 Suzuki Sidekick, Front. Fits 1996-1998 Suzuki X-90, Front. Fits 1989-1997 Geo Tracker, Front. Fits 1986-1995 Suzuki Samurai, Front. Fits 1988-1992 Audi 80, Front. Fits 1988-1990 Audi 90, Front. Fits 1982-1988 Volkswagen Quantum, Front. Fits 1980-1987 Audi 4000, Front.

What It Helps Address

• Transmission fluid seepage at the seal interface
• Contamination from dirt, dust, and moisture
• Wear-related loss of sealing tension
• Improper sealing from incorrect size or material selection
• Service replacement for aging manual transmission seals

Installation Notes and Tips

Verify bore diameter, outside diameter, and seal width before installation to confirm the seal matches the transmission housing and shaft interface. Inspect the sealing surface for scoring, corrosion, or debris before fitting the new seal, and make sure the lip seats evenly during installation. Confirm the vehicle application by year, make, model, and position before ordering; this part is listed for front and N/A positions depending on the vehicle.

Quality Assurance

FAG designs seals to meet vehicle manufacturer specifications and works with suppliers to maintain FAG quality standards. The seal construction and material selection are focused on protecting wheel end and drivetrain components from contamination while helping preserve grease or lubricant over the service life of the bearing or seal assembly.
