FAG SS3695 Manual Transmission Seal - Front

Overview of FAG SS3695 Manual Transmission Seal

The FAG SS3695 manual transmission seal is engineered to provide reliable sealing performance for a range of vehicles including Chevrolet, Dodge, GMC, Jeep, Pontiac, Saturn, Suzuki, and Toyota models. Designed with durable polyacrylate sealing material and a rubber spring auxiliary lip, this seal ensures effective protection against leaks and contamination.

• Seal Type: Rubber with spring and auxiliary lip for enhanced sealing
• Sealing Material: High-quality polyacrylate for durability and resistance
• Bore Diameter: 2.087 inches (53.01 mm)
• Seal Outside Diameter: 2.1 inches (53.34 mm)
• Seal Width: 1.26 inches (7.01 mm)

Technical Details and Specifications

The FAG SS3695 manual transmission seal features a precise bore diameter of 2.087 inches (53.01 mm) and an outside diameter of 2.1 inches (53.34 mm), ensuring a secure fit within the transmission housing. The seal width measures 1.26 inches (7.01 mm), providing adequate surface area for effective sealing. Constructed with a rubber spring auxiliary lip, this seal maintains consistent contact pressure to prevent fluid leakage under various operating conditions. The polyacrylate sealing material offers resistance to heat, oil, and wear, making it suitable for demanding manual transmission applications.

Compatible Vehicles and Applications

This manual transmission seal is compatible with a variety of vehicle makes and models, including Chevrolet Colorado and Silverado, Dodge Dakota and Ram, GMC Canyon, Jeep Cherokee, Grand Cherokee, and Wrangler, Pontiac Solstice, Saturn Sky, Suzuki XL-7, and Toyota 4Runner, Tacoma, Tundra, Supra, and Wagoneer. The part number SS3695 ensures correct fitment for these models, supporting reliable transmission performance and longevity.

Common Issues Addressed by FAG SS3695 Seal

• Prevents manual transmission fluid leaks that can cause shifting problems
• Protects transmission internals from dirt and contaminants
• Reduces wear on transmission components by maintaining proper lubrication
• Helps avoid costly transmission repairs due to seal failure
• Maintains consistent sealing pressure under varying temperature and pressure conditions

Installation Notes and Tips

When installing the FAG SS3695 manual transmission seal, ensure the transmission housing bore is clean and free of debris. Use appropriate tools to avoid damaging the seal during installation. Lubricate the sealing surface lightly with transmission fluid to facilitate proper seating. Verify the seal is installed flush and evenly to prevent leaks. It is recommended to inspect related transmission components for wear or damage during replacement.

Quality Assurance and Warranty

FAG is a recognized manufacturer of automotive sealing solutions, adhering to strict quality control standards. The SS3695 manual transmission seal is manufactured using premium materials and precision engineering to meet OEM specifications. While specific warranty details may vary, FAG products typically come with a limited warranty against manufacturing defects, ensuring confidence in product reliability and performance.
