FAG SS4041 Manual Transmission Output Shaft Seal - Right

Manual Transmission Output Shaft Seal for Mitsubishi and Hyundai

FAG SS4041 is a manual transmission output shaft seal built with a polyacrylate sealing material and a metal spring auxiliary-lip design. It is sized for a 2.406 in bore diameter, 2.412 in outside diameter, and 1.592 in width to support a precise seal at the transmission output shaft.

Compatible With select Mitsubishi Eclipse, Galant, Lancer, Outlander, Endeavor, Diamante, Mirage, and Hyundai Santa Fe, XG350, and XG300 applications, this seal is listed across a broad range of Asian vehicle fitments. FAG SS4041 is also cross-referenced to Bosch 15974 for the same application.

Key Features

• Manual transmission output shaft seal for transmission sealing service
• Metal, spring, and auxiliary lip seal type for controlled sealing contact
• Polyacrylate sealing material for transmission use
• 2.406 in bore diameter, 2.412 in outside diameter, 1.592 in width
• Fits select Mitsubishi and Hyundai vehicles across multiple model years
• Part number SS4041 for catalog and service identification

Detailed Product Overview

FAG SS4041 is engineered as a transmission sealing component for vehicles that require a manual transmission output shaft seal with exact dimensional control. The seal construction uses a metal spring and auxiliary lip to help maintain sealing contact at the shaft interface, while the polyacrylate material is selected for transmission sealing conditions. This makes SS4041 a direct-fit service part for many Mitsubishi Eclipse, Galant, Lancer, Outlander, Endeavor, Diamante, and Mirage applications, along with select Hyundai Santa Fe, XG350, and XG300 models.

Use SS4041 when servicing a leaking or worn output shaft seal on compatible vehicles. The part number SS4041 is commonly referenced in transmission gasket and sealing system catalogs, and it cross-references Bosch 15974 for the same application.

What This Seal Helps Address

• Transmission fluid seepage at the output shaft
• Contamination entering the transmission housing
• Seal wear from age, heat, and mileage
• Grease or lubricant loss at the sealing point
• Noise or drivability concerns related to low fluid level after a leak

Installation Notes and Tips

Verify bore diameter, outside diameter, and seal width before installation to confirm the seal matches the transmission housing. Inspect the shaft surface for scoring, corrosion, or wear before fitting the new seal, and clean the sealing area thoroughly so the lip can seat evenly. Confirm the vehicle application by year, make, model, and position before ordering; this part is listed for N/A and Right positions depending on the vehicle.

Quality Assurance

FAG specifies this seal using manufacturer-level dimensional and material requirements for the listed applications. The design follows the sealing demands of transmission service and is matched to the vehicle fitment data provided for Mitsubishi and Hyundai models.
