FAG SS6257 Automatic Transmission Output Shaft Seal - Right

Automatic Transmission Output Shaft Seal for Volvo

FAG SS6257 is an automatic transmission output shaft seal built with a polyacrylate sealing material and a rubber spring auxiliary-lip design. It is sized for a 70.053 mm bore diameter, 75.006 mm outside diameter, and 10.008 mm width to match the specified application.

Key Features

• Part number: SS6257
• Automatic transmission output shaft seal
• Seal type: rubber, spring, auxiliary lip
• Sealing material: polyacrylate
• Bore diameter: 70.053 mm
• Seal outside diameter: 75.006 mm
• Seal width: 10.008 mm
• Fits right-side Volvo applications listed below

Application Details

This FAG transmission seal is specified for Volvo C30, Volvo C70, and Volvo S40 right-side applications. Fits 2007-2013 Volvo C30, right; fits 2006-2013 Volvo C70, right; and fits 2001-2011 Volvo S40, right. The SS6257 is also referenced under Schaeffler global number 413 6257 100, and it cross-references Dorman - HELP 15768 for the same application.

What This Seal Helps Address

• Transmission fluid leakage at the output shaft area
• Contamination from dirt, dust, and moisture entering the seal area
• Wear at the shaft sealing surface caused by degraded sealing material
• Loss of fluid retention at the transmission end of the shaft

Installation Notes and Tips

Verify bore diameter, outside diameter, width, and right-side fitment before installation. Inspect the shaft and housing for scoring, corrosion, or debris that could affect sealing performance. Clean the sealing surfaces thoroughly and confirm the replacement seal seats evenly in the bore.

Quality Assurance

FAG designs seals to meet vehicle manufacturer specifications and works with suppliers to maintain FAG quality standards. The seal construction is selected to protect transmission components from contamination and help retain fluid over the service life of the bearing and related assembly.
