FCS 1337098R Suspension Strut and Coil Spring Assembly - Front Right

Front Right Strut Assembly for Hyundai Genesis

The FCS 1337098R is a suspension strut and coil spring assembly for the front right position on select Hyundai Genesis models. It is built around key dimensional specs that matter for fit and suspension travel: 19.84 in. compressed length, 25.35 in. extended length, and 5.51 in. stroke length.

Compatible with 2009-2014 Hyundai Genesis front right applications, this FCS suspension strut and coil spring assembly supports direct replacement needs for the Hyundai Genesis platform. The FCS line focuses on application-specific suspension components for common OE-style service work.

Key Features

• Part number: 1337098R
• Front right suspension strut and coil spring assembly
• Compressed length: 19.84 in.
• Extended length: 25.35 in.
• Stroke length: 5.51 in.
• Fits 2009-2011 Hyundai Genesis, front right
• Fits 2012-2014 Hyundai Genesis, front right, exc. R-Spec models

Detailed Description

FCS 1337098R is a suspension strut and coil spring assembly engineered for the front right corner of the Hyundai Genesis. The listed compressed, extended, and stroke measurements provide the dimensional reference needed when replacing a worn front suspension unit and matching the original suspension geometry. For buyers searching for a Hyundai Genesis front right strut assembly or an OE-style replacement for 2009-2014 Hyundai Genesis models, this part number offers a direct fit path by application.

This part cross-references Monroe Shocks & Struts (e.g., 172286, 182286) for the same application.

Common Repair Uses

• Front-end noise from a worn strut assembly
• Uneven ride height at the front right corner
• Excessive bounce or reduced damping response
• Suspension wear on a Hyundai Genesis front right strut
• Replacement for a damaged coil spring and strut assembly

Installation Notes and Tips

Verify the vehicle year, model, and front right position before ordering. This part fits 2009-2011 Hyundai Genesis, front right, and 2012-2014 Hyundai Genesis, front right, excluding R-Spec models. Compare the existing assembly dimensions and mounting orientation during service to confirm proper application of part number 1337098R.

Quality Assurance

FCS suspension components are cataloged by specific vehicle application and dimensional fitment data to support accurate replacement selection. Part number 1337098R is listed for the Hyundai Genesis front right position with defined compressed, extended, and stroke measurements for fitment verification.
