FCS 1345936 Suspension Strut and Coil Spring Assembly - Rear

Overview of FCS Suspension Strut and Coil Spring Assembly

The FCS Suspension Strut and Coil Spring Assembly, part number 1345936, is engineered for precise fitment on Jaguar models including the Super V8, Vanden Plas, XJ, XJ8, and XJR. Designed to restore suspension performance, this assembly features specific stroke and length measurements to ensure optimal vehicle handling and ride comfort.

• Compressed length: 13.27 inches
• Extended length: 18.46 inches
• Stroke length: 5.19 inches
• Compatible with Jaguar Super V8, Vanden Plas, XJ, XJ8, and XJR
• Part number: 1345936

FCS Brand Line Suspension Components

The FCS brand line focuses on suspension components designed to meet OEM specifications for reliable performance and durability. This suspension strut and coil spring assembly is part of the FCS lineup, which emphasizes precise engineering to maintain factory ride quality and handling characteristics for Jaguar vehicles. Using FCS parts helps ensure consistent suspension response and vehicle stability.

Product Details and Specifications

This suspension strut and coil spring assembly features a compressed length of 13.27 inches and an extended length of 18.46 inches, providing a stroke length of 5.19 inches. These dimensions are critical for maintaining proper suspension travel and damping characteristics on Jaguar models such as the XJ8 and XJR. The assembly integrates both the strut and coil spring, simplifying replacement and ensuring compatibility with the vehicle's suspension geometry.

Common Applications and Problem Resolution

• Restores suspension height and ride quality on Jaguar Super V8 and Vanden Plas models
• Addresses issues with worn or sagging coil springs
• Replaces leaking or damaged struts causing poor handling
• Improves vehicle stability and reduces body roll
• Eliminates uneven tire wear related to suspension faults

Installation Notes and Tips

Installation of the FCS suspension strut and coil spring assembly (part number 1345936) should be performed by a qualified technician familiar with Jaguar suspension systems. Proper torque specifications and alignment checks are essential after installation to ensure safe operation. It is recommended to replace struts and springs in pairs to maintain balanced handling characteristics.

Quality Assurance and Warranty

The FCS suspension strut and coil spring assembly is manufactured to meet or exceed OEM standards for Jaguar vehicles. While specific warranty details are not provided here, FCS products typically come with a limited warranty covering defects in materials and workmanship. Consult the product documentation or supplier for exact warranty terms.
