FCS 84134 Hood Lift Support

Hood Lift Support for Fiberglass Hood Applications

The FCS 84134 hood lift support is built for 1982-1992 Chevrolet Camaro and 1982-1992 Pontiac Firebird models equipped with a fiberglass hood. With a compressed length of 7.68 inches, an extended length of 12.87 inches, and a 5.2-inch stroke, this support is sized for controlled hood movement and consistent hold-open performance. If you are replacing a worn hood strut on a Camaro or Firebird fiberglass hood setup, FCS 84134 provides the correct fitment profile.

• Part number: 84134
• Compressed length: 7.68 in.
• Extended length: 12.87 in.
• Stroke length: 5.2 in.
• Fits fiberglass hood applications on select Chevrolet Camaro and Pontiac Firebird models
• Direct-fit hood lift support for body and hood service

Fitment Details

• Fits 1982-1992 Chevrolet Camaro, N/A, w/ Fiberglass Hood; FCS
• Fits 1982-1992 Pontiac Firebird, N/A, w/ Fiberglass Hood; FCS

FCS 84134 is a hood lift support for vehicles that use a fiberglass hood, where correct length and stroke are important for proper hood positioning. The compact compressed length and 12.87-inch extended length help match the hood’s opening arc, while the 5.2-inch stroke supports smooth movement during opening and closing. This part number, 84134, is a practical replacement choice for fiberglass-hood Camaro and Firebird applications.

Common Replacement Reasons

• Weak hood support that no longer holds the hood open
• Slow or uneven hood lift action
• Loss of pressure in the existing strut
• Incorrect hood positioning after hood service
• Need for a replacement on a fiberglass hood setup

Installation Notes

Verify hood style before ordering, since this application is listed for fiberglass hood vehicles only. Match the compressed length, extended length, and stroke length to the existing support before installation. Confirm the mounting points and hood alignment on the Chevrolet Camaro or Pontiac Firebird to ensure proper operation after replacement.

Quality Assurance

FCS 84134 is cataloged as a dedicated hood lift support for the listed Camaro and Firebird fiberglass hood applications. The brand line is FCS, and this part is identified by part number 84134 for straightforward application matching.
