FCS 86247 Liftgate Lift Support

Liftgate Support for Volkswagen Vanagon

The FCS 86247 liftgate lift support is built for 1983-1991 Volkswagen Vanagon applications with rear liftgate support requirements. With an extended length of 20.08 inches, compressed length of 11.69 inches, and 8.39 inches of stroke, it is sized to match the liftgate travel needed for this vehicle platform. This FCS 86247 replacement helps restore controlled liftgate movement on the Volkswagen Vanagon.

Key Features

• Direct-fit liftgate lift support for 1983-1991 Volkswagen Vanagon
• Extended length: 20.08 inches
• Compressed length: 11.69 inches
• Stroke length: 8.39 inches
• Designed for rear liftgate support applications
• FCS 86247 part number for accurate ordering and replacement matching

Detailed Description

FCS 86247 is a body hardware replacement for the rear liftgate on the Volkswagen Vanagon. The measured compressed length, extended length, and stroke length provide the dimensional reference needed when replacing a worn lift support on 1983-1991 Volkswagen Vanagon models. If the original support no longer holds the liftgate in position or the hatch feels heavy during opening, this part restores the correct support geometry for the application. This part cross-references Monroe Shocks & Struts (e.g., 172286) for the same application.

What It Helps Address

• Liftgate that drops instead of staying open
• Weak or inconsistent rear hatch support
• Excessive effort needed to raise the liftgate
• Loss of controlled liftgate movement on a Volkswagen Vanagon
• Replacement of a worn rear lift support on 1983-1991 Volkswagen Vanagon models

Installation Notes and Tips

Verify the compressed length, extended length, and stroke length against the original support before installation. Confirm the vehicle is a 1983-1991 Volkswagen Vanagon and match the rear liftgate application to the existing mounting points. Inspect the liftgate hinges and mounting hardware condition before replacing the support so the new part can operate smoothly.

Quality Assurance

FCS offers this liftgate lift support as a dimension-specific replacement for the listed Volkswagen Vanagon fitment. Part number 86247 should be matched to the vehicle year range and liftgate configuration before installation.
