FCS 86264 Back Glass Lift Support

Back Glass Lift Support for Highlander

FCS 86264 is a back glass lift support for the 2008-2013 Toyota Highlander. It is built to match the required compressed length, extended length, and stroke length for the rear glass application, helping restore controlled opening and holding action at the liftgate glass.

Key Features

• Fits 2008-2013 Toyota Highlander, N/A
• Compressed length: 10.28 in.
• Extended length: 16.42 in.
• Stroke length: 6.14 in.
• FCS part number 86264 for rear glass support replacement
• Brand line: FCS replacement components for body and glass applications

Product Details

This FCS back glass lift support is specified for the Toyota Highlander rear glass application and is sized to match the lift support geometry needed for proper operation. The 10.28-inch compressed length, 16.42-inch extended length, and 6.14-inch stroke length are the core dimensions that determine fit and movement range. If you are replacing a worn lift support on a 2008-2013 Toyota Highlander, FCS 86264 provides the dimensional match needed for the back glass to open and stay positioned as intended.

FCS focuses on replacement parts for body, glass, windows, and related components, and this product line is aimed at direct-fit service parts for common vehicle repair needs. FCS 86264 is a practical choice when the rear glass no longer lifts smoothly or does not remain supported during use.

Common Issues This Part Can Address

• Rear glass drops instead of staying open
• Liftgate glass opens with reduced support
• Weak or worn gas strut performance
• Uneven or inconsistent rear glass movement
• Need for a replacement back glass lift support on a Toyota Highlander

Installation Notes and Tips

Verify the existing support dimensions before installation to confirm the replacement matches the vehicle’s rear glass setup. Compare the compressed length, extended length, and stroke length to the original part, and inspect the mounting points for wear or damage before installing FCS 86264. For best results, replace a support only after confirming the application is 2008-2013 Toyota Highlander, N/A.

Quality Assurance

FCS 86264 is a dimension-specific replacement part for the Toyota Highlander rear glass application. Confirmed fitment is listed for 2008-2013 Toyota Highlander, and the part number 86264 should be matched to the vehicle before installation.
