Four Seasons 20385 HVAC Blower Motor Resistor - Front

Overview of Four Seasons Resistor Block 20385

The Four Seasons Resistor Block 20385 is designed specifically for Toyota Highlander HVAC systems. This HVAC blower motor resistor ensures proper fan speed control by regulating electrical current to the blower motor, maintaining consistent airflow within the vehicle's cabin.

• Compatible with Toyota Highlander models
• Part number 20385 for precise identification
• Female connector with square shape for secure fitment
• Four terminals supporting fixed speed #3 operation
• Type: Switches, designed for HVAC blower motor resistor applications

Features and Specifications

This resistor block features a female connector with a square shape, providing a reliable and secure connection to the vehicle's wiring harness. It includes four terminals that support a fixed speed #3 setting, which is essential for controlling the blower motor speed in the HVAC system. The part type is classified as switches, indicating its role in regulating electrical current flow within the blower motor circuit.

About the Four Seasons Resistor Block Product Line

The Four Seasons Resistor Block product line focuses on delivering components that regulate blower motor speeds in automotive HVAC systems. These resistor blocks are engineered to meet OEM specifications, ensuring compatibility and performance for vehicles like the Toyota Highlander. The 20385 resistor block is part of this line, providing a dependable solution for maintaining proper HVAC blower motor function.

Common Applications and Problem Resolution

This HVAC blower motor resistor is used to control the speed of the blower motor in Toyota Highlander vehicles. It addresses several common HVAC issues, including:

• Blower motor only working on one speed
• Inconsistent or no airflow from the vents
• HVAC blower motor failing to respond to speed adjustments
• Electrical resistance failure causing blower motor malfunction

Installation Notes and Tips

When installing the Four Seasons Resistor Block 20385, ensure the vehicle is powered off and the battery is disconnected to prevent electrical shock. Verify the connector gender and shape match the existing wiring harness—this part features a female, square-shaped connector with four terminals. Properly secure the resistor block in its mounting location to avoid vibration damage. Consult the Toyota Highlander service manual for specific removal and installation procedures.

Quality Assurance and Warranty

Four Seasons manufactures the Resistor Block 20385 to meet or exceed OEM standards for durability and performance. While specific warranty details are not provided here, Four Seasons products typically come with a limited warranty covering defects in materials and workmanship. Refer to the product packaging or manufacturer documentation for exact warranty terms.
