Four Seasons 20696 HVAC Blower Motor Resistor - Rear

Reliable HVAC Blower Motor Resistor for Chevrolet and GMC Vans

The Four Seasons Resistor Block 20696 is designed to restore proper blower motor function in select Chevrolet and GMC vans. This HVAC blower motor resistor ensures consistent fan speed control and reliable operation for your vehicle's heating and cooling system.

• Connector Gender: Female
• Connector Shape: Rectangular
• Number of Terminals: 4
• Type: Switches
• Part Number: 20696

About the Four Seasons Resistor Block Product Line

The Four Seasons Resistor Block line focuses on providing durable and precise HVAC blower motor resistors that meet or exceed OEM specifications. The 20696 resistor block is engineered to deliver consistent electrical resistance and reliable switching performance, helping maintain proper blower motor speeds in your Chevrolet Express or GMC Savana vans.

Product Details and Compatibility

This HVAC blower motor resistor features a female rectangular connector with four terminals, designed for direct replacement in Chevrolet Express 1500, 2500, 3500, and GMC Savana 1500, 2500, 3500 models, including the G30. The resistor block controls the blower motor speed by regulating current flow, ensuring your vehicle’s HVAC system operates efficiently.

Common Issues Addressed by Part Number 20696

• Inconsistent or non-functioning blower motor speeds
• Blower fan stuck on one speed setting
• Intermittent HVAC blower operation
• Complete loss of blower motor function
• Electrical resistance failure causing HVAC system malfunctions

Installation Notes and Tips

• Ensure vehicle ignition is off before installation
• Locate the blower motor resistor in the HVAC housing under the dashboard or glove box
• Disconnect the electrical connector carefully to avoid damage to the female rectangular connector
• Replace the resistor block with part number 20696, ensuring proper alignment of the four terminals
• Test blower motor speeds after installation to confirm proper operation

Quality Assurance and Warranty

Four Seasons Resistor Block 20696 is manufactured to meet industry standards for durability and performance. While specific warranty details may vary, Four Seasons products typically come with a limited warranty against defects in materials and workmanship, providing confidence in the part’s reliability for Chevrolet Express and GMC Savana vehicles.
