Four Seasons 20698 HVAC Blower Motor Resistor

Overview of Four Seasons Resistor Block 20698

The Four Seasons Resistor Block 20698 is designed to regulate the blower motor speed in select Hyundai and Kia vehicles. This HVAC blower motor resistor ensures proper fan operation for models such as the Hyundai Tucson and Kia Sportage, providing reliable climate control performance.

• Connector Gender: Female
• Connector Shape: Rectangular
• Number of Terminals: 4
• Type: Switches
• Part Number: 20698

Features and Specifications

This resistor block features a female rectangular connector with four terminals, allowing for secure and precise electrical connections within the HVAC system. The component functions as a switch type resistor block, controlling blower motor speeds by adjusting electrical resistance. It is engineered specifically for compatibility with Hyundai Spectra, Spectra5, Sportage, and Tucson models.

About the Four Seasons Resistor Block Product Line

The Four Seasons Resistor Block line focuses on providing durable and accurate blower motor resistors for various vehicle HVAC systems. This product line is designed to meet OEM specifications, ensuring consistent performance and fitment. The 20698 resistor block is part of this line, offering a reliable solution for maintaining proper blower motor function in Hyundai and Kia vehicles.

Common Applications and Issues Addressed

• Restores blower motor speed control in Hyundai Spectra and Kia Sportage
• Resolves issues with blower fan only working on certain speeds
• Fixes intermittent or no airflow from HVAC vents
• Eliminates overheating or electrical resistance failures in blower circuits
• Improves overall HVAC system reliability in Hyundai Tucson and Kia Spectra5

Installation Notes and Tips

Installation of the Four Seasons Resistor Block 20698 requires accessing the HVAC blower motor housing, typically located under the dashboard or behind the glove compartment. Ensure the vehicle’s battery is disconnected before installation to prevent electrical shorts. Verify the connector orientation matches the female rectangular design with four terminals for proper fitment. Consult the vehicle’s service manual for specific removal and replacement procedures.

Quality Assurance and Warranty

Four Seasons products are manufactured to meet or exceed OEM standards for durability and performance. The Resistor Block 20698 undergoes quality control testing to ensure reliable operation within the HVAC system. Warranty coverage details should be confirmed with the product documentation or supplier, as they may vary by region.
