Four Seasons 33374 A/C Receiver Drier
| Brand | Four Seasons 33374 |
|---|---|
| Body Diameter | 2.750 |
| Body Length | 7.000 |
| Bracket? | w/ Bracket |
| Connector B Type | Male Insert O-Ring |
| Connector Type | Male Insert O-Ring |
| Description | Filter Driers |
| Desiccant | Yes |
| Desiccant Replaceable | Not Replaceable |
| Dia. MM | 69.850 |
| Fuse Plug | No |
| Gasket / Seals? | Included |
| In Line Filter Material | Desiccant |
| In Line Filter Outlet Fitting Type | Male |
| Inlet Filter Fitting Thread Diameter | 0.625 |
| Inlet Filter Fitting Type | Male |
| Inlet Fitting Diameter | 0.375 |
| Inlet Fitting Type | Male Insert O-Ring |
| Inlet Fraction | 3/8 |
| Inlet IN | 0.375 |
| Inlet MM | 19.050 |
| Length MM | 177.800 |
| Material | Steel |
| Meets / Exceeds OEM? | Yes |
| Moisture Indicator Window | No |
| Mounting Bracket Included | Not Included |
| O-Ring A Number/Desc | [24606] / Green O-Ring |
| Outlet Fitting Type | Male Insert O-Ring |
| Outlet Fraction | 3/8 |
| Outlet IN | 0.375 |
| Outlet MM | 19.050 |
| Overall Depth IN | 7.000 |
| P. R. V.? | No |
| Service Port? | w/o Service Port |
| Sight Glass? | Yes |
| Stud? | No |
| Style | Steel Filter Drier |
| Switch Port Dia. IN | 0.250 |
| Switch Port Dia.MM | 6.350 |
| Switch Port? | w/ Switch Port |
| Type | Washer Not Included |
| Product line | Filter Drier |
| Fits | Volkswagen · 6 vehicles |
OE-spec replacement. Meets or exceeds OEM requirements for dependable system service.
Steel filter drier. Durable construction with desiccant to help remove moisture.
Sight glass included. Makes refrigerant condition easier to inspect during service.
Cross-references Continental 49021, CSF 3967 and Dayco 71369 for the same application. See all 32.
Four Seasons 33374 A/C Receiver Drier
Four Seasons 33374 is a steel A/C receiver drier built for HVAC service where moisture control and refrigerant cleanliness matter. It uses a male insert O-ring inlet and outlet, includes a sight glass, and is listed with a switch port for system-specific service needs.
Filter Drier Line Details
As part of the Four Seasons Filter Drier line, this receiver drier is an OE-style replacement focused on restoring proper A/C system function after component replacement or contamination. The steel body measures 2.750 inches in diameter and 7.000 inches in overall length, with a 3/8-inch inlet and 3/8-inch outlet. Four Seasons 33374 meets or exceeds OEM requirements and includes gasket/seals with green O-rings specified in the listing.
- Steel A/C receiver drier construction
- Male insert O-ring inlet and outlet connections
- Desiccant included for moisture removal
- Sight glass included for system inspection
- Switch port included; service port not included
- Meets or exceeds OEM requirements
Vehicle Fitment
Compatible with 1986-1991 Volkswagen Vanagon, from serial no. 24G0750000; filter drier. Fits 1986-1991 Volkswagen Vanagon, N/A.
This part cross-references UAC RD0818C for the same application.
What It Helps Address
- Moisture in the A/C system after compressor or line service
- Contaminants circulating through the refrigerant circuit
- Reduced cooling performance caused by a saturated desiccant
- Inspection needs through the integrated sight glass
- Replacement needs on Volkswagen Vanagon A/C service jobs
Installation Notes and Quality
Verify inlet and outlet sizing, O-ring condition, and switch-port requirements before installation. This Four Seasons 33374 receiver drier is intended for direct replacement use on the listed Volkswagen Vanagon application and should be installed with proper evacuation and recharge procedures after A/C system repair.
Quality is supported by OE-level fitment specifications, steel construction, included seals, and OEM-equivalent performance claims listed by the manufacturer.
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 1991 | Volkswagen | Vanagon | N/A | From Serial No. 24G0750000; Filter Drier |
| 1990 | Volkswagen | Vanagon | N/A | From Serial No. 24G0750000; Filter Drier |
| 1989 | Volkswagen | Vanagon | N/A | From Serial No. 24G0750000; Filter Drier |
| 1988 | Volkswagen | Vanagon | N/A | From Serial No. 24G0750000; Filter Drier |
| 1987 | Volkswagen | Vanagon | N/A | From Serial No. 24G0750000; Filter Drier |
| 1986 | Volkswagen | Vanagon | N/A | From Serial No. 24G0750000; Filter Drier |
