Four Seasons 33511 A/C Accumulator
| Brand | Four Seasons 33511 |
|---|---|
| Body Diameter | 3.500 |
| Body Length | 8.500 |
| Description | Accumulators |
| Dia. MM | 88.900 |
| Friction Material Attachment | w/o Service Port |
| Fuse Plug? | No |
| Inlet Fitting Diameter | 5/8 |
| Inlet Fitting Type | Male Springlock |
| Inlet IN | 0.625 |
| Inlet MM | 15.875 |
| Length MM | 215.900 |
| Material | Steel |
| Meets / Exceeds OEM? | Yes |
| Moisture Indicator? | No |
| Mounting Bracket Included | w/o Bracket |
| Mounting Hardware? | Not Included |
| O-Ring A Number/Desc | [24676] / Green O-Ring |
| O-Ring B Number/Desc | [24220] / Spring |
| O-Ring C Number/Desc | [24670] / Green O-Ring |
| O.E. Replacement? | Yes |
| Outlet Fitting Diameter | 0.625 |
| Outlet Fitting Type | Female Springlock |
| Outlet Fraction | 5/8 |
| Outlet MM | 15.875 |
| P. R. V.? | No |
| Stud? | No |
| Style | Complete Unit |
| Switch | w/ Switch Port |
| Switch Port Dia. IN | 0.250 |
| Switch Port Dia.MM | 12.000 |
| Type | Accumulator |
| Product line | Accumulator |
| Fits | Dodge · 3 vehicles |
OE replacement. Meets OEM specs for a direct-fit accumulator.
Steel construction. Provides a durable housing for the A/C system.
Complete unit. Includes the accumulator assembly in one ready-to-install package.
Cross-references AMS Automotive 4290, Carlson 16210 and Continental 49135 for the same application. See all 34.
Four Seasons 33511 A/C Accumulator
Four Seasons 33511 is a complete A/C accumulator built for OE-style replacement in the HVAC system. It is a steel accumulator with male springlock inlet and female springlock outlet connections, plus a switch port for system integration. Compatible With 1997-1999 Dodge Dakota applications, this part is built to meet or exceed OEM requirements.
Key Features
- Brand: Four Seasons Accumulator line
- Part number: 33511
- Type: A/C accumulator, complete unit
- Steel body construction
- Male springlock inlet, female springlock outlet
- Switch port included; no service port
- OE replacement design that meets or exceeds OEM specifications
- Fits 1997-1999 Dodge Dakota, accumulator application
Product Details
This Four Seasons accumulator is used in the air conditioning system to manage refrigerant flow and help protect the compressor from liquid refrigerant return. The housing measures 3.500 inches in body diameter and 8.500 inches in body length, with 5/8-inch inlet and outlet fittings. It includes the specified O-ring and spring sealing components for the listed connection points and is built as a direct replacement for the original equipment style layout used on 1997-1999 Dodge Dakota models. This part cross-references Monroe Shocks & Struts 172968 for the same application.
Common Problems This Part Can Address
- Loss of A/C cooling performance from a restricted or failing accumulator
- Moisture control issues in the refrigerant circuit
- Compressor protection concerns caused by improper refrigerant return
- Leaking springlock connections at the accumulator
- HVAC service needs on 1997-1999 Dodge Dakota, accumulator location
Installation Notes and Tips
Verify the inlet and outlet fitting style, switch port configuration, and body dimensions before installation. Replace the accumulator whenever the A/C system has been opened for major service, and evacuate and recharge the system according to factory procedures. Confirm the vehicle uses the listed springlock connection layout for 1997-1999 Dodge Dakota before ordering.
Quality Assurance
Four Seasons 33511 is an OE replacement accumulator that meets or exceeds OEM specifications. The Four Seasons Accumulator line is built for direct-fit HVAC service where original-style dimensions and connection types are required.
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 1999 | Dodge | Dakota | N/A | Accumulator |
| 1998 | Dodge | Dakota | N/A | Accumulator |
| 1997 | Dodge | Dakota | N/A | Accumulator |
