Four Seasons 36139 HVAC Blower Motor Relay

Reliable HVAC Blower Motor Relay for Lexus, Toyota, Pontiac

The Four Seasons Relay 36139 is a standard HVAC blower motor relay designed to meet or exceed OEM specifications. Engineered for 12-volt systems, this relay ensures consistent performance in various vehicle models including Lexus, Toyota, and Pontiac.

• 12 Volt operating voltage
• 60 Amp amperage rating for high current applications
• 5 blade terminals with male connector and terminal gender
• Square-shaped blue connector for secure fitment
• Standard resistor circuit type relay
• Compatible with multiple Lexus, Toyota, and Pontiac models
• Meets or exceeds OEM quality standards

Four Seasons Relay Product Line Overview

The Relay product line from Four Seasons focuses on delivering dependable electrical components for automotive HVAC systems. The Relay 36139 is part of this line, offering a standard relay style that supports blower motor functions with reliable switching and durability. This product line is designed to provide direct replacement parts that maintain factory performance and fitment.

Product Details and Specifications

The Four Seasons Relay 36139 operates at 12 volts and supports a 60 amp load, making it suitable for blower motor circuits requiring high current capacity. It features five blade terminals, all male, which facilitate straightforward installation and secure electrical connections. The blue, square-shaped connector ensures proper alignment and fit within the vehicle’s HVAC system. This relay uses a resistor circuit type and does not include a mounting bracket or skirt, reflecting its standard relay design.

Compatible Vehicles and Applications

This HVAC blower motor relay is compatible with a range of Lexus, Toyota, and Pontiac vehicles. Notable models include the Lexus RX330, ES300, and Land Cruiser; Toyota 4Runner, Camry, Celica, Corolla, Echo, Matrix, MR2 Spyder, RAV4, and Yaris; as well as the Pontiac Vibe. It is designed to replace factory relays in these vehicles, ensuring proper blower motor operation and climate control system functionality.

• Resolves blower motor failure or intermittent operation
• Addresses HVAC system electrical issues related to relay malfunction
• Fixes blower motor not turning on or running at incorrect speeds
• Eliminates overheating or relay contact wear problems
• Restores proper current flow in blower motor circuits

Installation Notes and Tips

When installing the Four Seasons Relay 36139, ensure the vehicle’s ignition is off and the battery is disconnected to prevent electrical shock. Verify the relay’s terminal configuration matches the original part. The male blade terminals and connector should fit securely into the vehicle’s wiring harness. No bracket or skirt is included, so use the existing mounting hardware if applicable. Proper installation will maintain HVAC blower motor performance and system reliability.

Quality Assurance and Warranty

The Four Seasons Relay 36139 meets or exceeds OEM standards for quality and durability. Manufactured to provide consistent electrical performance, this relay undergoes rigorous testing to ensure reliability in automotive HVAC applications. Warranty details are provided by Four Seasons and typically cover defects in material and workmanship under normal use.
