Four Seasons 36198 Engine Cooling Fan Motor Relay
| Brand | Four Seasons 36198 |
|---|---|
| Amperage Rating | 25 |
| Bracket? | No |
| Color | Black |
| Connector Gender | Male |
| Connector Qty | 1 |
| Connector Shape | Rectangular |
| Description | Relays |
| Meets / Exceeds OEM? | Yes |
| Style | Standard Relay |
| Terminal Gender | Male |
| Terminal Quantity | 4 |
| Terminal Type | Blade |
| Type | Standard |
| Voltage | 12 |
| Product line | Relay |
| Fits | Mazda · 33 vehicles |
OE direct replacement. Meets or exceeds OEM requirements for dependable relay performance.
Standard relay. 12-volt, 25-amp design with a 4-blade terminal layout.
Compact connector design. Rectangular male connector helps ensure a secure electrical connection.
Cross-references Four Seasons 20182, Four Seasons 36198 and A08950 for the same application. See all 5.
Engine Cooling Fan Relay for Mazda Applications
Four Seasons Relay 36198 is a standard 12-volt engine cooling fan motor relay built with a 4-blade male terminal layout and a rectangular single-connector design. It meets or exceeds OEM requirements and is specified for Mazda cooling and A/C relay applications where reliable electrical switching is critical.
Four Seasons Relay line components are built for direct replacement use in vehicle electrical systems, with standard relay construction and OE-style terminal configuration for service work on Mazda 3, Mazda 6, MX-5 Miata, RX-8, CX-7, and MPV applications.
Key Features
- Part number 36198
- 12-volt standard relay design
- 25 amp amperage rating
- 4 blade terminals with male connector and male terminal gender
- 1 rectangular connector, black housing
- Standard relay style and standard type construction
- Meets or exceeds OEM specifications
Detailed Description
Four Seasons 36198 is an engine cooling fan motor relay used in Mazda electrical systems to control fan and related relay functions. The relay’s 12V, 25A specification, blade terminals, and rectangular connector format support OE-style replacement in vehicles that require this exact relay configuration. This part number 36198 also cross-references A08950 for the same application.
Compatible fitment includes 2012 Mazda CX-7; 2010 Mazda MX-5 and MX-5 Miata to 2/1/10; 2009 Mazda 3, 3 Sport, MX-5, MX-5 Miata, and RX-8; 2008 Mazda 6; 2007-2008 Mazda CX-7; 2007 Mazda 6; 2006 Mazda 6, MX-5, MX-5 Miata, and MPV; 2004-2008 Mazda 3 and RX-8; and 2002-2006 Mazda MPV. Search terms such as Mazda 3 cooling fan relay, Mazda RX-8 engine cooling fan relay, and Mazda MX-5 Miata relay replacement align with this application coverage.
Common Issues This Relay Can Address
- Cooling fan not switching on when commanded
- Intermittent fan operation caused by relay contact wear
- A/C relay circuit faults tied to the cooling fan relay path
- Electrical switching problems in Mazda relay-controlled circuits
- Relay replacement during cooling system electrical diagnosis
Installation Notes and Tips
Verify the terminal count, connector shape, voltage, and amperage rating against the original relay before installation. Confirm the vehicle’s relay location and application notes, especially on Mazda MX-5 and MX-5 Miata models with the 2/1/10 cutoff note. Match the existing relay exactly to avoid circuit mismatch.
Quality Assurance
Four Seasons lists this relay as meeting or exceeding OEM requirements, making it a direct-fit service part for specified Mazda applications. The Four Seasons Relay line is intended for standard replacement use in factory relay circuits.
| Year | Make | Model | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|
| 2012 | Mazda | CX-7 | — | — | N/A | Relay |
| 2010 | Mazda | MX-5 | — | — | N/A | To 2/1/10; Relay |
| 2010 | Mazda | MX-5 Miata | — | — | N/A | To 2/1/10; Relay |
| 2009 | Mazda | 3 | — | — | N/A | Relay |
| 2009 | Mazda | 3 Sport | — | — | N/A | Relay |
| 2009 | Mazda | MX-5 | — | — | N/A | Relay |
| 2009 | Mazda | MX-5 Miata | — | — | N/A | Relay |
| 2009 | Mazda | RX-8 | — | — | N/A | Relay |
| 2008 | Mazda | 3 | — | — | N/A | A/C Compressor Cut-Out Relay also known as Engine Cooling Fan Motor Relay.; Relay |
| 2008 | Mazda | 6 | 2.3L | L4 | N/A | Relay |
| 2008 | Mazda | CX-7 | — | — | N/A | A/C Compressor Cut-Out Relay also known as Engine Cooling Fan Motor Relay.; Relay |
| 2008 | Mazda | RX-8 | — | — | N/A | A/C Compressor Cut-Out Relay also known as Engine Cooling Fan Motor Relay.; Relay |
| 2007 | Mazda | 3 | — | — | N/A | A/C Compressor Cut-Out Relay also known as Engine Cooling Fan Motor Relay.; Relay |
| 2007 | Mazda | 6 | — | — | N/A | A/C Compressor Cut-Out Relay also known as Engine Cooling Fan Motor Relay.; Relay |
| 2007 | Mazda | CX-7 | — | — | N/A | A/C Compressor Cut-Out Relay also known as Engine Cooling Fan Motor Relay.; Relay |
| 2007 | Mazda | RX-8 | — | — | N/A | A/C Compressor Cut-Out Relay also known as Engine Cooling Fan Motor Relay.; Relay |
| 2006 | Mazda | 3 | — | — | N/A | A/C Compressor Cut-Out Relay also known as Engine Cooling Fan Motor Relay.; Relay |
| 2006 | Mazda | 6 | 2.3L | L4 | N/A | Relay |
| 2006 | Mazda | MPV | — | — | N/A | A/C Compressor Cut-Out Relay also known as Engine Cooling Fan Motor Relay.; Relay |
| 2006 | Mazda | MX-5 | — | — | N/A | Relay |
| 2006 | Mazda | MX-5 Miata | — | — | N/A | Relay |
| 2006 | Mazda | RX-8 | — | — | N/A | A/C Compressor Cut-Out Relay also known as Engine Cooling Fan Motor Relay.; Relay |
| 2005 | Mazda | 3 | — | — | N/A | A/C Compressor Cut-Out Relay also known as Engine Cooling Fan Motor Relay.; Relay |
| 2005 | Mazda | 6 | 2.3L | L4 | N/A | Relay |
| 2005 | Mazda | MPV | — | — | N/A | A/C Compressor Cut-Out Relay also known as Engine Cooling Fan Motor Relay.; Relay |
| 2005 | Mazda | RX-8 | — | — | N/A | A/C Compressor Cut-Out Relay also known as Engine Cooling Fan Motor Relay.; Relay |
| 2004 | Mazda | 3 | — | — | N/A | A/C Compressor Cut-Out Relay also known as Engine Cooling Fan Motor Relay.; Relay |
| 2004 | Mazda | 6 | 2.3L | L4 | N/A | Relay |
| 2004 | Mazda | MPV | — | — | N/A | A/C Compressor Cut-Out Relay also known as Engine Cooling Fan Motor Relay.; Relay |
| 2004 | Mazda | RX-8 | — | — | N/A | A/C Compressor Cut-Out Relay also known as Engine Cooling Fan Motor Relay.; Relay |
| 2003 | Mazda | 6 | 2.3L | L4 | N/A | Relay |
| 2003 | Mazda | MPV | — | — | N/A | A/C Compressor Cut-Out Relay also known as Engine Cooling Fan Motor Relay.; Relay |
| 2002 | Mazda | MPV | — | — | N/A | A/C Compressor Cut-Out Relay also known as Engine Cooling Fan Motor Relay.; Relay |
