Four Seasons 54935 A/C Evaporator Core

Overview of Four Seasons Evaporator Core 54935

The Four Seasons Evaporator Core 54935 is designed for reliable HVAC performance in select Hyundai and Kia vehicles. This A/C evaporator core ensures efficient cooling by effectively removing heat and moisture from the air inside your vehicle.

• Core dimensions: 9.25 inches width, 9.5 inches height, 3.1875 inches depth
• Material: Durable aluminum construction for corrosion resistance
• Inlet and outlet fittings: No. 8 captive o-ring type for secure connections
• Includes two green o-rings (part number 24659) for proper sealing
• Plate and fin design for optimized heat exchange

Four Seasons Evaporator Core Product Line Details

The Evaporator Core line by Four Seasons focuses on delivering precise fit and function for vehicle HVAC systems. This product line features plate and fin cores made from aluminum, providing a balance of durability and thermal efficiency. The 54935 evaporator core is engineered to meet OEM specifications, ensuring compatibility and performance in Hyundai and Kia models.

Detailed Product Description and Specifications

The Four Seasons Evaporator Core 54935 measures 9.25 inches in width, 9.5 inches in height, and has a depth of approximately 3.19 inches (81 mm). Constructed from aluminum, it offers resistance to corrosion and maintains structural integrity under typical operating conditions. Both the inlet and outlet fittings use captive o-ring seals with an outside diameter of No. 8, which helps prevent refrigerant leaks and ensures a tight connection within the HVAC system. The core’s plate and fin design enhances heat transfer efficiency, contributing to effective air conditioning performance in your vehicle.

Compatible Vehicles and Common Applications

• Hyundai Magentis
• Hyundai Santa Fe
• Hyundai Sonata
• Kia Optima
• Kia Sorento
• Kia XG300
• Kia XG350

This evaporator core is specifically designed for these Hyundai and Kia models, providing a direct replacement for worn or damaged components in the HVAC system.

Common Issues Addressed by Replacing the Evaporator Core

• Reduced cooling efficiency or weak A/C airflow
• Leaks causing refrigerant loss and system underperformance
• Unpleasant odors due to mold or debris buildup inside the core
• Excess moisture or fogging inside the vehicle cabin
• HVAC system noise related to damaged or clogged evaporator cores

Installation Notes and Tips

Installation of the Four Seasons Evaporator Core 54935 requires proper handling of refrigerant lines and seals. Ensure the two included green o-rings (part number 24659) are correctly seated on the No. 8 captive fittings to prevent leaks. It is recommended to have the HVAC system evacuated and recharged by a certified technician after installation. Verify fitment with your specific Hyundai or Kia model year before proceeding.

Quality Assurance and Warranty Information

Four Seasons manufactures the Evaporator Core 54935 to meet industry standards for durability and performance. The aluminum construction and plate & fin design contribute to long service life. While specific warranty details are not provided here, Four Seasons typically offers coverage against defects in materials and workmanship. Consult product documentation or the manufacturer for exact warranty terms.
