Four Seasons 56505 A/C Suction and Liquid Line Hose Assembly

Overview of Four Seasons Hose Assembly 56505

The Four Seasons Hose Assembly 56505 is designed specifically for Dodge and Plymouth vehicles, including Caravan, Grand Caravan, Grand Voyager, and Voyager models. This A/C suction and liquid line hose assembly ensures reliable performance in your vehicle's HVAC system by maintaining proper refrigerant flow and pressure.

• Constructed from durable aluminum and rubber materials
• Equipped with male o-ring and male insert o-ring ends for secure connections
• Compatible with R134-a refrigerant systems
• Includes gasket and fittings for a complete installation
• Features a service port with quick disconnect for easy maintenance
• Designed for both high and low system pressure applications

Four Seasons Hose Assembly Product Line Details

The Four Seasons Hose Assembly product line focuses on providing OEM replacement hoses and assemblies that meet or exceed original equipment specifications. The 56505 hose assembly is part of this line, offering a direct fit solution without the need for additional modifications. This line emphasizes quality materials and precise engineering to ensure compatibility and durability in HVAC systems.

Detailed Product Description

This hose assembly combines aluminum and rubber components to deliver strength and flexibility required for effective refrigerant transport. It features a male o-ring on one end and a male insert o-ring on the other, both sealed with green o-rings ([24606] and [24610]) to prevent leaks. The assembly supports R134-a refrigerant and is suitable for both high and low-pressure sides of the system. Included are all necessary gaskets and fittings, such as the filter drier flange port gasket ([24124]) and additional gasket ([24138]), ensuring a complete and secure installation. The hose assembly also includes a service port with an M8 x 1.0 thread and quick disconnect, facilitating easy system servicing without disassembly.

Common Applications and Issues Addressed

• Replacement of worn or damaged A/C suction and liquid line hoses
• Resolving refrigerant leaks caused by cracked or deteriorated hoses
• Restoring proper refrigerant flow and system pressure in Dodge Caravan and Plymouth Voyager HVAC systems
• Eliminating issues related to faulty or missing service ports for maintenance access
• Addressing compatibility problems with aftermarket or incorrect hose assemblies

Installation Notes and Tips

• Ensure vehicle compatibility with Dodge Caravan, Grand Caravan, Grand Voyager, or Plymouth Voyager models before installation
• Verify that all included gaskets and o-rings are properly seated to prevent leaks
• Use appropriate tools to connect male o-ring and male insert o-ring fittings securely
• Check the service port for proper thread engagement and quick disconnect functionality
• Inspect the HVAC system for any additional damaged components during installation

Quality Assurance and Warranty

The Four Seasons Hose Assembly 56505 is an OEM replacement part designed to meet original equipment standards for fit, form, and function. It includes all necessary seals and fittings to ensure a leak-free installation. While specific warranty details are not provided, Four Seasons products typically come with a limited warranty against defects in materials and workmanship, supporting reliable performance in your Dodge or Plymouth vehicle's HVAC system.
