Four Seasons 56794 A/C Refrigerant Discharge / Suction Hose Assembly

Overview of Four Seasons Hose Assembly 56794

The Four Seasons Hose Assembly 56794 is designed specifically for Jeep TJ and Wrangler models, providing reliable A/C refrigerant discharge and suction hose functionality. Engineered with durable aluminum and rubber materials, this hose assembly supports R134-a refrigerant systems and includes essential components for a secure fit.

• Constructed from aluminum and rubber for durability and flexibility
• Compatible with R134-a refrigerant systems
• Includes green O-rings and sealing washers for leak prevention
• Equipped with a male springlock discharge end and female springlock suction end
• Features a service port with R134-a quick disconnect and a bracket for secure mounting
• O.E. replacement part ensuring proper fit and function

Four Seasons Hose Assembly Product Line Details

The Hose Assembly product line by Four Seasons focuses on delivering complete A/C hose solutions that combine both discharge and suction lines in one assembly. This line is designed to meet original equipment specifications, providing a direct replacement for factory parts. The 56794 model includes integrated features such as a switch service port and manifold compatibility, making it suitable for maintaining the HVAC system integrity in Jeep TJ and Wrangler vehicles.

Detailed Product Description

This A/C refrigerant discharge and suction hose assembly is built to handle the demands of Jeep TJ and Wrangler air conditioning systems. The discharge end measures 0.500 inches (12.7 mm) with a male springlock style, while the suction end is 0.625 inches (15.875 mm) with a female springlock connection. The assembly includes multiple green O-rings ([24668], [24670], [24606]) and sealing washers ([24354]) to ensure a tight, leak-free seal. Although fittings are not included, the hose comes with a mounting bracket and a service port featuring a quick disconnect for R134-a refrigerant, facilitating maintenance and service.

Common Applications and Issues Addressed

• Replacement of worn or damaged A/C refrigerant hoses in Jeep TJ and Wrangler models
• Resolving refrigerant leaks caused by degraded seals or O-rings
• Restoring proper refrigerant flow in the discharge and suction lines
• Addressing issues related to faulty or missing service ports for system diagnostics
• Securing hose assembly with included bracket to prevent vibration damage

Installation Notes and Tips

When installing the Four Seasons Hose Assembly 56794, ensure all old O-rings and seals are removed and replaced with the included green O-rings and sealing washers to prevent leaks. The male and female springlock ends require proper alignment and secure locking to maintain system integrity. The included bracket should be used to mount the hose assembly firmly, reducing stress on connections. Note that fittings and switches are not included and may need to be sourced separately depending on your vehicle’s configuration.

Quality Assurance and Warranty

Four Seasons Hose Assembly 56794 is an original equipment replacement part, manufactured to meet or exceed OEM standards for fit, form, and function. The inclusion of factory-style O-rings and sealing washers supports long-term reliability. While specific warranty details are not provided here, Four Seasons products typically come with a limited warranty covering defects in materials and workmanship.
