Four Seasons 57281 A/C Compressor

Overview of Four Seasons Reman Compressor 57281

The Four Seasons Reman Compressor 57281 is a remanufactured A/C compressor designed for select Buick, Oldsmobile, and Pontiac models. Engineered to work with R134a refrigerant and compatible with Pag 150 oil, this compressor ensures reliable air conditioning performance for vehicles like the Buick Skylark and Pontiac Grand Am.

• Compatible refrigerant type: R134a
• Includes oil filled with Pag 150 compatible refrigerant oil
• Five-groove serpentine pulley for efficient belt engagement
• Spade terminal type and coil for electrical connection
• Includes clutch with a maximum diameter of 5 inches
• Ear mount installation type with 1.25-inch distance from clutch to mounting flange
• Equipped with two green O-rings (part number 24615) for sealing
• Coil voltage rated at 12 volts
• Block mount suction port with O-rings and sealing washer included

Details on the Four Seasons Reman Compressor Line

The Reman Compressor line by Four Seasons offers remanufactured A/C compressors that meet strict quality standards to restore factory-level performance. This line focuses on providing reliable, cost-effective replacements with included oil and clutch components, designed specifically for GM vehicles. The 57281 model is part of this line, ensuring compatibility and durability for Buick, Oldsmobile, and Pontiac A/C systems.

Product Description and Specifications

This Four Seasons Reman Compressor 57281 is a V5 type compressor designed for use with R134a refrigerant and Pag 150 oil, which is included in the unit. The compressor features a 5-groove serpentine pulley with a 5-inch diameter, optimized for smooth belt operation. The clutch assembly is included and has a maximum diameter of 5 inches, with a coil positioned at the 2 o'clock clock position. The compressor uses a spade terminal type coil and is designed for ear mount installation, with a 1.25-inch distance from clutch to mounting flange. The suction port is block mount style and comes with O-rings and a sealing washer to ensure a secure fit. This remanufactured compressor is equipped with an R12 control valve, which is important to note if retrofitting the system.

Compatible Vehicles and Common Applications

• Buick Calais and Skylark models requiring R134a A/C compressors
• Oldsmobile Cutlass Calais with compatible A/C clutch and compressor needs
• Pontiac Grand Am models needing a remanufactured V5 compressor
• Replacement for worn or failing compressors in these GM vehicles
• Solves issues such as loss of cooling, clutch failure, and refrigerant leaks

Installation Notes and Tips

• Ensure system is evacuated and flushed before installation
• Use compatible Pag 150 refrigerant oil included with the compressor
• Verify clutch coil voltage and terminal type for proper electrical connection
• Replace O-rings with the included green O-rings (part number 24615) to prevent leaks
• Mount using ear mount points and confirm 1.25-inch clutch to flange distance

Quality Assurance and Warranty

This remanufactured compressor undergoes rigorous testing to meet OEM specifications for performance and durability. The Four Seasons Reman Compressor 57281 includes all necessary oil and clutch components to ensure proper operation. While mounting hardware is not included, the product is backed by Four Seasons' quality standards. Please consult the warranty information provided by Four Seasons for coverage details.
