Four Seasons 57955 A/C Compressor

Overview of Four Seasons Reman Compressor 57955

The Four Seasons Reman Compressor 57955 is a remanufactured A/C compressor designed for select GM vehicles including Buick, Cadillac, Chevrolet, and Pontiac models. Engineered to work with R134a refrigerant and compatible with Pag 150 oil, this compressor ensures reliable air conditioning performance for vehicles like the Camaro, Caprice, and Firebird.

• Compatible Refrigerant: R134a
• Oil Type: Pag 150 (oil filled included)
• Pulley Groove Quantity: 6
• Coil Voltage: 12V with pin terminal
• Includes clutch assembly with 5-inch maximum diameter
• Mounting Type: Type XIII (all ears, no threads)
• Pulley Diameter: 5 inches (127 mm)
• Compressor Type: HD6
• O-Rings included for sealing washer suction port
• Designed for serpentine belt systems

Detailed Product Description

This Four Seasons Reman Compressor 57955 is a remanufactured HD6 type compressor specifically built for GM vehicles such as the Chevrolet Impala, Cadillac Fleetwood, and Pontiac Roadmaster. It comes pre-filled with the appropriate amount of Pag 150 oil and is compatible with R134a refrigerant, ensuring proper lubrication and cooling system efficiency. The compressor features a 6-groove pulley designed for serpentine belt applications, with a pulley diameter of 5 inches (127 mm) and a clutch included for seamless integration. The coil is positioned at the 10 o'clock clock position and operates at 12 volts with a pin-type terminal connection. Mounting is via a Type XIII system, which uses all ears without threads, and the package includes two O-rings for the sealing washer suction port to maintain system integrity.

Reman Compressor Product Line

The Four Seasons Reman Compressor line offers remanufactured compressors that meet strict quality standards to restore A/C system functionality. This product line focuses on providing reliable, cost-effective replacements that include essential components such as the clutch and oil fill, reducing installation time and ensuring compatibility with original equipment specifications. The Reman Compressor 57955 is part of this line, designed to deliver consistent performance for GM vehicles requiring HD6 compressors.

Common Applications and Issues Addressed

• Replacement for failed or leaking A/C compressors in Buick, Cadillac, Chevrolet, and Pontiac vehicles
• Restores proper refrigerant flow and pressure in R134a systems
• Solves clutch engagement problems with included clutch assembly
• Addresses pulley wear or damage affecting serpentine belt operation
• Eliminates oil contamination or loss within the compressor

Installation Notes and Tips

• Ensure compatibility with vehicle make and model before installation
• Use the included O-rings for proper sealing of the suction port
• Verify the serpentine belt condition and pulley alignment during installation
• Check coil voltage and terminal type for electrical compatibility
• Mount using Type XIII mounting points; mounting hardware is not included

Quality Assurance and Warranty

The Four Seasons Reman Compressor 57955 undergoes rigorous remanufacturing processes to meet OEM standards. It includes the necessary oil fill and clutch assembly to ensure proper operation. While mounting hardware is not included, the compressor is designed for straightforward installation on compatible GM vehicles. Warranty coverage details should be confirmed with the parts provider or manufacturer documentation.
