Four Seasons 73424 HVAC Mode Door Actuator
| Brand | Four Seasons 73424 |
|---|---|
| Door Linkage | Male |
| Mounting Ear Qty. | 4 |
| Style | HVAC Air Door Actuator |
| Terminal Pin Qty. | 7 |
| Product line | Air Door Actuator |
| Fits | Honda · 13 vehicles |
Air door actuator. Controls HVAC airflow with a direct actuator design.
7-pin design. Uses a seven-terminal connection for reliable electrical control.
4 mounting ears. Provides a secure, stable installation.
Cross-references Four Seasons 73424, Global Parts Distributors LLC 1712482 and 79140SZTG41 for the same application. See all 7.
Four Seasons 73424 HVAC Mode Door Actuator
The Four Seasons 73424 is an HVAC mode door actuator for vehicles equipped with an air door actuator style control. It is built with a male door linkage, 4 mounting ears, and a 7-terminal pin layout for the specified applications. This part is used on select Honda Fit and Honda Insight models.
Key Features
- Four Seasons Air Door Actuator product line
- HVAC mode door actuator for mode and recirculation door control
- Male door linkage design
- 4 mounting ears for secure installation
- 7-terminal pin electrical connection
- Direct-fit application for select Honda HVAC systems
Application Details
Four Seasons 73424 is a replacement HVAC mode door actuator for select Honda vehicles. Fits 2013-2014 Honda Fit, N/A, where it controls recirculation door functionality. Fits 2010-2014 Honda Insight, N/A. This part cross-references Global Parts Distributors LLC 1712482 for the same application.
What It Helps Fix
- Incorrect air distribution from the dash vents
- Recirculation door movement problems
- HVAC mode selection that does not respond properly
- Clicking or binding from the actuator area
- Loss of consistent cabin airflow control
Installation Notes
Verify connector style, terminal pin count, linkage type, and mounting ear layout before installation. Match the original actuator to the vehicle’s HVAC control system and confirm fitment for the exact Honda Fit or Honda Insight year listed. After installation, cycle the HVAC controls to confirm proper door movement and mode selection.
Quality Assurance
Four Seasons supplies HVAC replacement components for air management and climate control service. Part number 73424 is built to match the listed application details for select Honda Fit and Honda Insight models.
| Year | Make | Model | Submodel | Liters | Cylinders | Fuel Type | Position | Notes |
|---|---|---|---|---|---|---|---|---|
| 2014 | Honda | Fit | — | — | — | — | N/A | HVAC Mode Door Actuator controls recirculation door functionality.; Air Door Actuator |
| 2014 | Honda | Insight | LX | — | — | — | N/A | Air Door Actuator |
| 2014 | Honda | Insight | EX | — | — | — | N/A | Air Door Actuator |
| 2013 | Honda | Fit | EV | -L | -- | ELECTRIC | N/A | HVAC Mode Door Actuator controls recirculation door functionality.; Air Door Actuator |
| 2013 | Honda | Insight | — | — | — | — | N/A | Air Door Actuator |
| 2013 | Honda | Insight | LX | — | — | — | N/A | Air Door Actuator |
| 2013 | Honda | Insight | EX | — | — | — | N/A | Air Door Actuator |
| 2012 | Honda | Insight | — | — | — | — | N/A | Air Door Actuator |
| 2012 | Honda | Insight | LX | — | — | — | N/A | Air Door Actuator |
| 2012 | Honda | Insight | EX | — | — | — | N/A | Air Door Actuator |
| 2011 | Honda | Insight | LX | — | — | — | N/A | Air Door Actuator |
| 2011 | Honda | Insight | EX | — | — | — | N/A | Air Door Actuator |
| 2010 | Honda | Insight | — | — | — | — | N/A | Air Door Actuator |
