Four Seasons 73504 HVAC Mode Door Actuator - Left
| Brand | Four Seasons 73504 |
|---|---|
| Position | Left |
| Door Linkage | Male |
| Mounting Ear Qty. | 3 |
| Style | HVAC Air Door Actuator |
| Terminal Pin Qty. | 5 |
| Product line | Air Door Actuator |
| Fits | Kia · 10 vehicles |
Air door actuator. Controls HVAC airflow with a 5-pin, 3-ear design.
Mode door actuator. Directs cabin air through the HVAC system.
Cross-references Four Seasons 73504, 97154E4000 and A60504 for the same application. See all 4.
Four Seasons 73504 HVAC Air Door Actuator
The Four Seasons 73504 HVAC mode door actuator is a direct-fit air door actuator for the left side of select Kia Soul EV models. It is built with a 5-pin terminal layout, a male door linkage, and a 3-ear mounting design for applications that require precise HVAC door movement.
Key Features
- HVAC air door actuator for mode door control
- Male door linkage for the specified application
- 3 mounting ears for secure installation
- 5-terminal pin configuration
- Fits left-side HVAC applications on select Kia Soul EV vehicles
- Four Seasons part number 73504
Product Details
Four Seasons Air Door Actuator line components are built for HVAC control systems that direct airflow through the dash vents, floor outlets, or defrost passages. This Four Seasons 73504 actuator is specified for 2015-2017 Kia Soul EV left-side applications, plus 2018 Kia Soul EV left-side vehicles from 3/1/2017 and 2019 Kia Soul EV left-side vehicles to 12/2018. If you are searching for a Kia Soul EV HVAC mode door actuator, Four Seasons 73504 provides the correct fitment details for the listed vehicles.
This part cross-references 97154E4000 and A60504 for the same application.
What It Helps Fix
- Incorrect airflow direction from the dash vents, floor vents, or defrost outlets
- HVAC mode door movement that does not respond properly
- Air distribution stuck in one position
- Temperature or airflow routing issues caused by a failed actuator
- Clicking or inconsistent HVAC door operation
Installation Notes and Tips
Verify the connector style, mounting ear layout, and left-side location before installation. Confirm the vehicle build date for 2018 and 2019 Kia Soul EV applications, since fitment is limited to the dates shown. After installation, cycle the HVAC controls to confirm the mode door moves through each position correctly.
Quality Assurance
Four Seasons manufactures HVAC components for replacement applications with attention to OE-style fit and function. Use the listed fitment details and part number 73504 to confirm the correct actuator before ordering.
| Year | Make | Model | Submodel | Liters | Cylinders | Fuel Type | Position | Notes |
|---|---|---|---|---|---|---|---|---|
| 2019 | Kia | Soul EV | Base | — | — | — | Left | To 12/2018; Air Door Actuator |
| 2019 | Kia | Soul EV | Luxury | — | — | — | Left | To 12/2018; Air Door Actuator |
| 2019 | Kia | Soul EV | + | — | — | — | Left | To 12/2018; Air Door Actuator |
| 2018 | Kia | Soul EV | Base | — | — | — | Left | From 3/1/2017; Air Door Actuator |
| 2018 | Kia | Soul EV | E | — | — | — | Left | From 3/1/2017; Air Door Actuator |
| 2018 | Kia | Soul EV | Luxury | — | — | — | Left | From 3/1/2017; Air Door Actuator |
| 2018 | Kia | Soul EV | + | — | — | — | Left | From 3/1/2017; Air Door Actuator |
| 2017 | Kia | Soul EV | — | — | — | — | Left | Air Door Actuator |
| 2016 | Kia | Soul EV | — | -L | -- | ELECTRIC | Left | Air Door Actuator |
| 2015 | Kia | Soul EV | — | -L | -- | ELECTRIC | Left | Air Door Actuator |
