Four Seasons 73513 HVAC Floor Mode Door Actuator - Right

Overview of Four Seasons Air Door Actuator 73513

The Four Seasons Air Door Actuator 73513 is designed specifically for HVAC floor mode control in select Lexus and Toyota vehicles. This actuator ensures precise airflow direction within the climate control system, maintaining comfort and functionality in your 4Runner or GX470.

• HVAC floor mode door actuator with arm-type door linkage
• Equipped with 4 mounting ears for secure installation
• Features 5 terminal pins for reliable electrical connection
• Compatible with Lexus 4Runner and Toyota GX470 models
• Part number 73513 for accurate identification and fitment

Detailed Product Description

The Four Seasons Air Door Actuator 73513 is a critical component in the HVAC system, responsible for controlling the floor mode air door position. Its arm-style door linkage provides precise mechanical movement, ensuring the correct airflow path inside the vehicle cabin. The actuator includes four mounting ears, which facilitate a stable and secure fit within the HVAC housing. Additionally, the five terminal pins allow for consistent electrical connectivity, supporting the actuator’s motor function. This part is engineered to meet the specifications required for Lexus 4Runner and Toyota GX470 models, making it a direct replacement for the original equipment.

About the Four Seasons Air Door Actuator Product Line

The Air Door Actuator line from Four Seasons focuses on delivering reliable HVAC door actuators designed to control airflow modes within vehicle climate systems. This product line emphasizes compatibility and durability, providing components that integrate seamlessly with factory HVAC controls. The 73513 actuator is part of this line, offering a precise fit and function for floor mode air door applications in select Lexus and Toyota vehicles.

Common Applications and Issues Resolved

• Restores proper floor mode airflow control in HVAC systems
• Eliminates inconsistent or stuck air door movement
• Resolves HVAC noise caused by faulty door actuators
• Corrects temperature control issues related to air door positioning
• Prevents HVAC system error codes related to actuator malfunction

Installation Notes and Tips

• Ensure vehicle compatibility with Lexus 4Runner or Toyota GX470 before installation
• Disconnect the battery to prevent electrical shorts during replacement
• Carefully remove the old actuator, noting the position of the arm linkage
• Align the new actuator’s arm linkage and mounting ears precisely for proper operation
• Verify electrical connections on the 5 terminal pins are secure before reassembly

Quality Assurance and Warranty

Four Seasons manufactures the Air Door Actuator 73513 to meet OEM standards for fit and function. While specific warranty details may vary, Four Seasons typically offers coverage against defects in materials and workmanship. This ensures that the actuator performs reliably when installed in compatible Lexus 4Runner and Toyota GX470 vehicles.
