Four Seasons 76316 Engine Cooling Fan Assembly

Radiator Fan Assembly for Mazda MX-5

Four Seasons 76316 is an OE replacement engine cooling fan assembly built for Mazda MX-5 and Mazda MX-5 Miata applications. It combines a plastic blade, metal components, and an included shroud in a 12-volt electrical design for radiator fan service.

Key Features

• OE replacement radiator fan assembly for direct-fit cooling system service
• 12-volt electrical motor assembly with 4-terminal connector
• Plastic blade construction with rigid blade design and black housing finish
• Included plastic shroud for radiator fan mounting
• OE mount design with 4-terminal male connector
• Performance rated for cooling system replacement applications
• Fan clutch is not mounted within the assembly

Product Details

Four Seasons Radiator Fan Assy. 76316 is built as an engine cooling fan assembly for Mazda MX-5 and Mazda MX-5 Miata models. The assembly uses a single rigid plastic fan blade, a plastic shroud, and a 12-volt electrical motor layout with OE mount fitment. This part cross-references 253803J000 and 621415 for the same application. If you are replacing a worn radiator fan assembly on a 2006-2014 Mazda MX-5 or Mazda MX-5 Miata, or a 2015 Mazda MX-5 / MX-5 Miata with fan blade and motor service, Four Seasons 76316 provides the correct OE-style configuration.

Common Replacement Reasons

• Radiator fan motor failure causing poor airflow through the radiator
• Cracked or damaged fan blade affecting cooling performance
• Broken shroud or mounting wear at the radiator fan location
• Electrical connector or terminal damage at the fan assembly
• Overheating concerns tied to reduced engine cooling fan operation

Installation Notes

Verify OE mount alignment, connector style, and shroud dimensions before installation. This assembly uses a 4-terminal male connector and does not include mounting hardware. Confirm radiator fan location fitment and match the vehicle application before replacing the original unit. Fits 2006-2014 Mazda MX-5, N/A. Fits 2006-2014 Mazda MX-5 Miata, N/A. Fits 2015 Mazda MX-5, N/A, w/ Fan Blade and Motor; Radiator Fan Assy. Fits 2015 Mazda MX-5 Miata, N/A, w/ Fan Blade and Motor; Radiator Fan Assy.

Quality Assurance

Four Seasons 76316 is listed as an OE replacement and performance rated cooling fan assembly. The Four Seasons Radiator Fan Assy. line is built for direct replacement use in radiator fan service where OE-style fitment and electrical configuration are required.
