Four Seasons 77307 A/C Compressor

Reman A/C Compressor for OE-Style Replacement

Four Seasons Reman Compressor 77307 is a remanufactured A/C compressor built for R134a systems using PAG 46 oil. It includes the clutch, uses a 12-volt coil, and features an RPM sensor for speed monitoring in supported applications.

Compatible With 1999 Chrysler Sebring, 1995-1999 Dodge Avenger, 1995-1999 Mitsubishi Eclipse, 1995-1998 Chrysler Sebring, and 1986-1989 Acura Integra applications listed with the 10PA17C compressor.

Key Features

• Four Seasons Reman Compressor line
• Part number 77307
• Remanufactured 10PA17C compressor with clutch included
• R134a refrigerant type with PAG 46 oil specification
• RPM sensor / speed sensor included
• Serpentine belt pulley with 5-groove design
• Pad mount suction and discharge ports
• 12V coil with pin terminal type
• Oil filled and ready for system service
• May require use of OE manifold

Product Details

The Four Seasons Reman Compressor 77307 is a Nippondenso-type, tangent-mount A/C compressor built around the 10PA17C design. It measures 152.400 mm at the pulley diameter, uses a 6.000-inch clutch, and includes the clutch assembly for applications that call for a reman compressor with clutch. The unit is configured for serpentine belt drive and pad-mount ports, with the compressor manifold port gasket listed as O-ring A.

This part cross-references Gates 34857 for the same application. It is also listed among interchange references including 11177307 and DW77307. For shoppers searching for a reman A/C compressor for 1995-1999 Mitsubishi Eclipse, 1995-1999 Dodge Avenger, or 1986-1989 Acura Integra, this part number 77307 matches the specified 10PA17C compressor applications.

What It Helps Address

• Loss of cabin cooling from a worn or seized compressor
• Noisy compressor operation tied to internal wear
• Incorrect refrigerant circulation in an R134a system
• Clutch engagement issues in compressor-equipped HVAC systems
• Speed-sensor related compressor monitoring faults in supported vehicles

Installation Notes

Verify the vehicle uses the 10PA17C compressor configuration before ordering. This compressor is listed with pad-mount suction and discharge ports and may require use of the OE manifold. Mounting hardware is not included. Confirm refrigerant oil type, system cleanliness, and belt alignment before installation, and replace the compressor manifold port gasket as needed during service.

Fits 1999 Chrysler Sebring, N/A; Fits 1995-1999 Dodge Avenger, N/A; Fits 1995-1999 Mitsubishi Eclipse, N/A; Fits 1995-1998 Chrysler Sebring, N/A; Fits 1986-1989 Acura Integra, N/A.

Quality Assurance

Four Seasons remanufactured compressors are built for OE-style service applications and are cataloged with detailed compressor, clutch, and sensor specifications to support accurate replacement selection. Part number 77307 is identified for the listed vehicle applications and compressor configuration.
