Four Seasons 77322 A/C Compressor

Reliable A/C Compressor for Toyota RAV4

The Four Seasons Reman Compressor 77322 is designed specifically for Toyota RAV4 models requiring a dependable remanufactured A/C compressor. Engineered to work with R134a refrigerant and compatible with Pag 46 oil, this compressor ensures efficient air conditioning performance.

• Remanufactured Four Seasons Reman Compressor part number 77322
• Compatible with Toyota RAV4 A/C systems using R134a refrigerant
• Includes clutch and oil for immediate installation
• Features a 5-groove serpentine pulley with a 4.75-inch diameter
• Equipped with an RPM sensor switch and pin-type terminal
• Designed with a tangent mount and pad mount suction and discharge ports
• Coil voltage rated at 12 volts with a 1-wire lead coil clock position

Four Seasons Reman Compressor Product Line

The Four Seasons Reman Compressor line offers remanufactured compressors that meet strict quality standards to restore factory performance. This product line focuses on providing reliable, cost-effective replacements with included oil and clutch assemblies, designed to match original equipment specifications for vehicles like the Toyota RAV4.

Detailed Product Features and Specifications

This Four Seasons A/C compressor (part number 77322) is a Nippondenso 10pa15l type compressor, remanufactured to ensure durability and performance. It is pre-filled with oil and includes the clutch assembly, which has a maximum diameter of 4.75 inches. The pulley features five grooves and a serpentine belt design with a belt width of 0.875 inches (22.225 mm). The compressor uses a pin-type terminal and includes a speed sensor switch with an RPM sensor for precise operation. The mounting type is tangent mount with a distance from clutch to mounting flange of approximately 3.09 inches (78.74 mm). Both suction and discharge ports are pad mount style, and the coil operates at 12 volts with a single wire lead.

Common Applications and Problem Resolution

• Replacement for failing or noisy A/C compressors in Toyota RAV4 vehicles
• Restores proper refrigerant flow and pressure in R134a systems
• Solves issues related to clutch failure or pulley wear
• Addresses compressor oil leaks or contamination problems
• Improves overall air conditioning system efficiency and cooling performance

Installation Notes and Tips

When installing the Four Seasons Reman Compressor 77322, ensure compatibility with the Toyota RAV4 model year and confirm the use of R134a refrigerant and Pag 46 oil. The compressor includes the clutch and oil, but mounting hardware is not included and may need to be sourced separately. The unit may require the use of the original equipment manifold due to the pad mount port design. Proper torque specifications and alignment of the serpentine belt are essential for optimal operation.

Quality Assurance and Warranty

This remanufactured compressor undergoes rigorous testing to meet industry standards for performance and reliability. Four Seasons provides a limited warranty on the Reman Compressor line, covering defects in materials and workmanship. This ensures that the part number 77322 delivers consistent operation for Toyota RAV4 vehicles equipped with compatible A/C systems.
