Four Seasons 77324 A/C Compressor

Overview of Four Seasons Reman Compressor 77324 for Toyota RAV4

The Four Seasons Reman Compressor 77324 is a remanufactured A/C compressor designed specifically for Toyota RAV4 models. Engineered to work with R134a refrigerant and compatible with Pag 46 oil, this compressor ensures reliable air conditioning performance for your vehicle.

• Compatible Refrigerant: R134a
• Compatible Refrigerant Oil Type: Pag 46
• Switch Type: RPM sensor included
• Oil Filled: Yes, oil is included
• Pulley Groove Quantity: 5 grooves for serpentine belt
• Terminal Type: Pin
• Clutch Included with a maximum diameter of 5.875 inches
• Coil Voltage: 12 volts with 1 wire lead coil clock position
• Mounting Type: Tangent mount with 2.09375 inch distance from clutch to mounting flange
• Compressor Type: 10p13c Nippondenso style
• Discharge and Suction Port Type: Pad mount
• O-Rings Included: Four green O-rings (part number 24613)

Details on Four Seasons Reman Compressor Product Line

The Four Seasons Reman Compressor line offers remanufactured compressors that meet strict quality standards to restore factory-level performance. This remanufactured compressor 77324 is built to provide a cost-effective replacement option for Toyota RAV4 owners, maintaining compatibility with original refrigerant and oil specifications while including essential components such as the clutch and speed sensor switch.

Technical Description and Features

This remanufactured A/C compressor features a 10p13c Nippondenso design, optimized for Toyota RAV4 air conditioning systems using R134a refrigerant. The compressor comes pre-filled with Pag 46 oil, ensuring proper lubrication and longevity. It includes a clutch assembly with a 5.875-inch maximum diameter and a 5-groove pulley designed for serpentine belts. The clutch coil operates at 12 volts with a single wire lead, and the unit is equipped with an RPM sensor switch for accurate system monitoring. The tangent mount design and precise mounting dimensions (2.09375 inches from clutch to mounting flange) facilitate straightforward installation. Both discharge and suction ports use pad mount types, and four green O-rings are included to ensure proper sealing during installation.

Common Applications and Issues Addressed

• Replacement for failing or noisy A/C compressors in Toyota RAV4 models
• Restores proper refrigerant flow and pressure in R134a systems
• Resolves clutch engagement problems with included clutch assembly
• Addresses oil leakage or compressor seizure due to worn internal components
• Improves air conditioning performance and system reliability

Installation Notes and Tips

• May require use of original equipment (OE) manifold for proper fitment
• Mounting hardware is not included; reuse existing hardware or source separately
• Ensure system is evacuated and flushed before installation to prevent contamination
• Verify compatibility with Toyota RAV4 model year and engine specifications
• Check clutch coil voltage and wiring connections for proper operation

Quality Assurance and Warranty

The Four Seasons Reman Compressor 77324 undergoes rigorous remanufacturing processes to meet OEM standards. It includes essential components such as the clutch and speed sensor switch to ensure full functionality. While mounting hardware is not included, the compressor is supplied with necessary O-rings and pre-filled oil. Warranty coverage details should be confirmed with the parts provider or installer to ensure protection against defects and premature failure.
