Four Seasons 84802 Engine Coolant Water Outlet

Engine Coolant Water Outlet for Jeep Applications

Four Seasons Water Outlet 84802 is an aluminum engine coolant outlet built for OE-style cooling system service. It includes the gasket or seal and is supplied in a thermostat-free outlet style for direct replacement use on select Jeep Cherokee, Comanche, Wagoneer, Wrangler, J10, CJ7, Grand Wagoneer, Scrambler, and CJ5 applications.

Key Features

• Aluminum construction for cooling system durability
• Gasket or seal included for a cleaner service replacement
• Outlet style without thermostat
• Inlet diameter: 1.204 in.
• Maximum height: 2.179 in.
• Bolt hole center to bolt hole center: 2.78 in. and 2.875 in.
• Mounting flange width: 0.431 in.
• Meets or exceeds OEM requirements
• Four Seasons Water Outlet line for engine coolant components

Product Details

This Four Seasons 84802 engine coolant water outlet is designed as an OE-style replacement for cooling system service where the outlet housing is worn, corroded, or leaking. The aluminum body helps maintain a stable coolant path, while the included gasket or seal supports proper sealing at the mounting surface. Because this unit is supplied without a thermostat, it is the correct choice when replacing the outlet housing only. Four Seasons 84802 is listed for select Jeep Cherokee, Jeep Comanche, Jeep Wagoneer, Jeep Wrangler, Jeep J10, Jeep CJ7, Jeep Grand Wagoneer, Jeep Scrambler, and Jeep CJ5 models across 1981-1990 applications.

This part cross-references Motorad 4802KT and CH4802 for the same application.

Common Cooling System Issues It May Address

• Coolant seepage at the outlet housing
• Corrosion or pitting in the original aluminum or cast housing
• Warped sealing surfaces that cause leaks
• Damaged bolt-hole mounting points
• Restricted coolant flow caused by a deteriorated outlet assembly

Installation Notes and Tips

• Verify inlet diameter, bolt-hole spacing, and mounting flange dimensions before installation.
• Inspect the mating surface and clean all old gasket material before assembly.
• Replace the thermostat separately if the vehicle service procedure calls for it; thermostat is not included.
• Refill and bleed the cooling system according to the vehicle manufacturer procedure after installation.
• Confirm fitment for your specific Jeep Cherokee, Comanche, Wagoneer, Wrangler, J10, CJ7, Grand Wagoneer, Scrambler, or CJ5 by year and engine configuration.

Quality Assurance

Four Seasons 84802 is engineered to meet or exceed OEM specifications for engine coolant components. The Four Seasons Water Outlet line is built for direct-fit cooling system service on select Jeep applications, including 1981-1990 Jeep Cherokee, 1986-1990 Jeep Comanche, and 1987-1990 Jeep Wrangler models.
