Four Seasons 84897 Engine Coolant Water Outlet

Engine Coolant Water Outlet for OE-Style Cooling Repair

Four Seasons Water Outlet 84897 is an engine coolant water outlet built for direct cooling-system service on select applications, including Chevrolet LUV, Isuzu Pickup, Isuzu I-Mark, Isuzu Trooper, and Plymouth Acclaim. It is an OE-style replacement part with aluminum construction, a gasket or seal included, and no thermostat included.

Key Features

• Aluminum construction for cooling-system durability
• Aluminum / cast iron material specification listed for application matching
• Gasket or seal included for service replacement
• Outlet style without thermostat
• Meets or exceeds OEM requirements
• Inlet diameter: 0.932 in.
• Maximum height: 2.570 in.
• Bolt hole center to bolt hole center: 2.672 in. and 2.6875 in.
• Mounting flange width: 0.454 in.

Product Details

This Four Seasons Water Outlet line part is designed as an engine coolant outlet for vehicles that use a separate thermostat housing arrangement. Part number 84897 is built to match OE-style dimensions and mounting points, helping maintain proper coolant routing at the engine. It cross-references Dorman - Conduct-Tite 84897 for the same application. For shoppers searching for a water outlet for 1975-1982 Chevrolet LUV, 1981-1987 Isuzu Pickup, 1981-1985 Isuzu I-Mark, 1984-1985 Isuzu Trooper, or 1989 Plymouth Acclaim, this part number 84897 is a direct-fit reference to review against the original component.

What This Part Helps Address

• Coolant leakage at the outlet housing
• Cracked or corroded original water outlet
• Improper sealing at the coolant connection
• Restricted coolant flow caused by a damaged outlet
• Service replacement for a thermostat-less outlet assembly

Installation Notes and Tips

Confirm inlet diameter, bolt spacing, and mounting flange dimensions before installation. Clean the mating surface thoroughly and replace the gasket or seal during service, since it is included with the part. This outlet is supplied without a thermostat, so reuse or replace the thermostat separately only if your vehicle’s cooling system requires one.

Quality Assurance

Four Seasons lists this water outlet as meeting or exceeding OEM requirements, making it a technical replacement choice for cooling-system repair. Verify vehicle year, make, model, and engine-side outlet configuration against the original part before installation.
