Four Seasons 85002 Engine Coolant Water Outlet - Upper

Engine Coolant Water Outlet for Ford Applications

Four Seasons 85002 is an engine coolant water outlet built for Ford cooling system service where a direct-fit outlet housing is needed. It is made from aluminum, with aluminum/cast iron listed in the product data, and includes a gasket or seal for service replacement. This outlet is specified without a thermostat and meets or exceeds OEM requirements.

Compatible with Ford E-150, E-250, E-350 Super Duty, F-150, F-250, F-350, Expedition, Excursion, Navigator, and related Econoline applications across the listed model years, Four Seasons 85002 supports cooling system repairs on upper and non-position-specific outlet locations. This part cross-references Motorad (e.g., 5002KT, CH5002) for the same application.

Key Features

• Part number: 85002
• Engine coolant water outlet / outlet housing
• Aluminum construction with aluminum/cast iron listed in the product data
• Gasket or seal included
• Thermostat not included
• Style: without thermostat
• Meets or exceeds OEM requirements
• Bolt hole center to bolt hole center: 2.875 in. and 2.89 in.
• Maximum height: 3.2553 in.
• Inlet diameter: 1.536 in.
• Mounting flange width: 0.394 in.

Product Details

Four Seasons Water Outlet 85002 is an engine coolant component used to route coolant through the cooling system at the outlet housing location. The aluminum construction supports corrosion resistance and stable fitment, while the included gasket or seal helps complete the repair at the mating surface. Because the thermostat is not included, this part is appropriate when replacing the outlet housing only or when reusing a separate thermostat assembly.

Use this Four Seasons 85002 water outlet when servicing Ford cooling systems that call for an OE-style outlet housing on E-Series vans, F-Series trucks, Expedition, Excursion, or Navigator applications. The listed dimensions and OEM-level specification help match the original mounting and hose connection points.

Common Repair Uses

• Replacing a leaking coolant outlet housing
• Repairing coolant seepage at the gasket surface
• Restoring proper coolant routing at the thermostat housing area
• Addressing cracked or corroded outlet components
• Servicing Ford cooling systems with an OE-style outlet replacement

Installation Notes and Tips

• Verify the inlet diameter, bolt spacing, and mounting flange dimensions before installation.
• Confirm whether your vehicle uses an upper or non-position-specific outlet configuration.
• Inspect the mating surface and coolant hoses for wear before assembly.
• Replace coolant and bleed the system according to the vehicle service procedure after installation.
• Check the thermostat separately, since it is not included with this part.

Quality Assurance

Four Seasons 85002 is listed as meeting or exceeding OEM requirements for the specified applications. The Four Seasons Water Outlet line is built for direct replacement service in engine coolant systems, with fitment coverage across 1997-2019 Ford E-Series, F-Series, Expedition, Excursion, and Lincoln Navigator applications.
