Four Seasons 85107 Engine Coolant Water Outlet

Engine Coolant Water Outlet for Chrysler and Dodge

Four Seasons 85107 is an engine coolant water outlet built for select Chrysler, Dodge, and Plymouth applications from 1980-1996. It is an OE-style outlet with the gasket or seal included, and it is supplied without a thermostat for applications that reuse the existing thermostat assembly.

Key Features

• Brand: Four Seasons Water Outlet
• Part number: 85107
• Engine coolant water outlet, outlet type
• Style: without thermostat
• Gasket or seal included
• Material construction: aluminum / cast iron and steel
• Meets or exceeds OEM requirements
• Inlet diameter: 0.883 in
• Maximum height: 2.581 in
• Bolt hole center to bolt hole center: 2.52 in and 2.625 in
• Mounting flange width: 0.182 in

Product Details

The Four Seasons Water Outlet line is focused on engine coolant components that support proper coolant routing at the thermostat housing area. This Four Seasons 85107 outlet is designed for direct replacement use on a wide range of older Chrysler, Dodge, and Plymouth vehicles, including Dodge Dakota, Dodge Caravan, Dodge Shadow, Plymouth Voyager, and Chrysler LeBaron applications. It cross-references Gates 31305 for the same application.

Use this part when servicing a leaking or corroded coolant outlet on vehicles such as Fits 1987-1996 Dodge Dakota, N/A; Fits 1984-1995 Dodge Caravan, N/A; and Fits 1982-1994 Chrysler LeBaron, N/A. The part number 85107 is also commonly searched alongside Chrysler LeBaron water outlet replacement, Dodge Caravan coolant outlet, and Dodge Dakota engine coolant water outlet queries.

Common Issues This Part Can Address

• Coolant seepage at the outlet or gasket surface
• Corrosion or pitting in the coolant passage housing
• Cracked or warped water outlet housing
• Improper sealing at the thermostat housing area
• Coolant loss related to a deteriorated outlet assembly

Installation Notes

Confirm inlet diameter, bolt-hole spacing, and mounting dimensions before installation. This outlet does not include a thermostat, so reuse or replace the thermostat separately as needed. Clean the mating surfaces thoroughly, inspect the hose connection for wear, and install the included gasket or seal on a dry, debris-free surface for proper sealing.

Quality Assurance

Four Seasons lists this water outlet as meeting or exceeding OEM requirements, making it a direct-fit replacement option for maintenance and repair work on select Chrysler, Dodge, and Plymouth cooling systems.
