Four Seasons 85111 Engine Coolant Water Outlet

Four Seasons Water Outlet 85111

The Four Seasons 85111 engine coolant water outlet is an aluminum replacement part for cooling system service on select Honda applications. It is built as an outlet without a thermostat and meets or exceeds OEM requirements for direct-fit replacement use.

Key Features

• Aluminum construction for cooling system durability
• Outlet style, without thermostat
• Gasket or seal not included
• Meets or exceeds OEM specifications
• Inlet diameter: 1.069 in.
• Bolt hole center to bolt hole center: 1.65625 in.
• Maximum height: 2.669 in.
• Mount flange width: 0.402 in.

Product Details

This Four Seasons Water Outlet line component is designed for engine coolant routing at the thermostat housing area where a replacement outlet is needed without an integrated thermostat. The aluminum body supports corrosion resistance in a cooling system environment, while the direct-fit dimensions help maintain proper alignment at the mounting points. This part cross-references Motorad (e.g., 5111KT, CH5111) for the same application. Four Seasons 85111 is listed for 1990-1993 Honda Accord and 1992-1996 Honda Prelude applications.

Common Repair Issues

• Coolant leaks at the outlet housing
• Cracked or warped original water outlet
• Corrosion around the coolant passage
• Improper sealing at the thermostat housing area
• Replacement needed during cooling system service

Installation Notes

Verify the inlet diameter, bolt spacing, and mounting flange dimensions before installation. Because the gasket or seal is not included, reuse is not assumed and the correct sealing components should be selected separately. This outlet is specified without a thermostat, so confirm the vehicle’s cooling system configuration before ordering. Fits 1990-1993 Honda Accord and 1992-1996 Honda Prelude, with the listed outlet application.

Quality Assurance

Four Seasons states that this part meets or exceeds OEM requirements for the listed application. The part number 85111 is also supported by multiple interchange references, including Four Seasons 85111, which helps confirm application matching for service replacement.
