Four Seasons 86247 Engine Coolant Water Outlet - Upper

Engine Coolant Water Outlet for Volkswagen Applications

Four Seasons 86247 is an engine coolant water outlet built for Volkswagen cooling system service. This plastic outlet is an OE-style replacement that meets or exceeds OEM requirements and is supplied without a thermostat or gasket/seal.

Use Four Seasons Water Outlet 86247 when servicing upper or outlet-side coolant connections on select Volkswagen Atlas, Passat, CC, Touareg, and Passat CC applications. The part number 86247 is also a direct cross-reference for common replacement searches.

Key Features

• Brand: Four Seasons Water Outlet
• Part number: 86247
• Engine coolant water outlet, type: outlet
• Plastic construction for cooling system service
• Style: without thermostat
• Thermostat not included
• Gasket or seal not included
• Meets or exceeds OEM requirements
• Inlet diameter: 1.55 in.
• Bolt hole center to bolt hole center: 2.65 in.
• Maximum height: 3.61 in.
• Mounting flange width: 0.32 in.

Product Details

Four Seasons 86247 is part of the Water Outlet line within the Belts and Cooling category, focused on engine coolant components. It is built as a plastic coolant outlet for Volkswagen cooling system repair where the original outlet has cracked, warped, or begun leaking. This part cross-references Gates CO34930 for the same application.

Fits 2018-2020 Volkswagen Atlas, N/A; Fits 2018 Volkswagen Passat, N/A; Fits 2012-2016 Volkswagen Passat, N/A; Fits 2017 Volkswagen CC, Upper; Fits 2017 Volkswagen Passat, Upper; Fits 2017 Volkswagen Touareg, Upper; Fits 2012-2016 Volkswagen CC, N/A; Fits 2011-2016 Volkswagen Touareg, N/A; Fits 2012 Volkswagen Passat CC, N/A; Fits 2009-2011 Volkswagen CC, N/A.

Common Repair Uses

• Replacing a cracked or leaking coolant outlet housing
• Restoring proper coolant routing in the engine cooling system
• Repairing a damaged upper coolant outlet on select Volkswagen models
• Addressing coolant loss from a worn plastic outlet assembly
• Servicing a thermostat-less outlet location during cooling system repair

Installation Notes and Tips

Confirm the inlet diameter, bolt spacing, and mounting dimensions before installation. Because the gasket or seal is not included, reuse only if serviceable or source the correct sealing components separately. Inspect the mating surfaces, flush any contaminated coolant, and verify the system is properly filled and bled after installation.

Quality Assurance

Four Seasons 86247 is manufactured to meet or exceed OEM specifications for the listed Volkswagen applications. Verify fitment by year, model, and position before ordering.
