FTE 3104722 Clutch Slave Cylinder

Clutch Slave Cylinder for Manual Transmission Service

FTE CSC 3104722 is a clutch slave cylinder for manual transmission repair, built with a 22.22 mm bore diameter and a push rod included for direct hydraulic actuation. It is a dry unit, with installation instructions included, and it serves the clutch release system on the outside of the transmission bell-housing.

Compatible with select Isuzu Amigo, Pickup, Rodeo, and Trooper applications, this part supports clutch fork movement for smooth disengagement during shifting. The FTE 3104722 is a practical replacement choice when servicing hydraulic clutch components on 1988-1994 Isuzu manual transmission vehicles.

Key Features

• Clutch slave cylinder for manual transmission hydraulic release systems
• 22.22 mm bore diameter for specified hydraulic operation
• Push rod included
• Installation instructions included
• Fluid filled: No
• Pin included: No
• Switch included: No
• Brand line: CSC

Product Details

The FTE CSC line focuses on clutch hydraulic components for power transfer between the engine and transmission. This clutch slave cylinder is positioned outside the bell-housing and actuates the clutch fork, which works with the release bearing to disengage the clutch. Part number 3104722 is engineered for manual transmission service where consistent hydraulic movement and proper release travel are required. This part cross-references LuK LSC168 for the same application.

Vehicle Fitment

• Fits 1989-1994 Isuzu Amigo, CSC
• Fits 1988-1992 Isuzu Pickup, CSC
• Fits 1991-1992 Isuzu Rodeo, W/O Borg Warner; CSC
• Fits 1988-1991 Isuzu Trooper, CSC

Common Repair Symptoms

• Hard or inconsistent clutch pedal feel
• Difficulty disengaging the clutch during shifts
• Hydraulic clutch release problems
• Clutch fork movement issues at the transmission
• Fluid loss or internal wear in the slave cylinder

Installation Notes

Verify the bore diameter, mounting style, and vehicle application before installation. Inspect the clutch hydraulic system, clutch fork, and release bearing for wear during service. Bleed the hydraulic system after installation to restore proper pedal and release operation. Use the included installation instructions as a reference during replacement.

Quality Assurance

FTE CSC 3104722 is built for clutch hydraulic service using OEM-oriented engineering and application-specific design. The part number 3104722 is listed for confirmed Isuzu fitments and is supported by interchange references for catalog matching during replacement selection.
